2SD2165-M

Description
6A, 100V, NPN, Si, POWER TRANSISTOR, PLASTIC PACKAGE-3
CategoryDiscrete semiconductor    The transistor
File Size114KB,6 Pages
ManufacturerRenesas Electronics Corporation
Websitehttps://www.renesas.com/
Download Datasheet Parametric View All

2SD2165-M Overview

6A, 100V, NPN, Si, POWER TRANSISTOR, PLASTIC PACKAGE-3

2SD2165-M Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codecompli
Shell connectionISOLATED
Maximum collector current (IC)6 A
Collector-emitter maximum voltage100 V
ConfigurationSINGLE
Minimum DC current gain (hFE)800
JESD-30 codeR-PSFM-T3
JESD-609 codee0
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeNPN
Certification statusNot Qualified
surface mountNO
Terminal surfaceTIN LEAD
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
Nominal transition frequency (fT)110 MHz
Base Number Matches1
DATA SHEET
SILICON POWER TRANSISTOR
2SD2165
NPN SILICON EPITAXIAL TRANSISTOR
FOR LOW-FREQUENCY POWER AMPLIFIERS AND LOW-SPEED SWITCHING
The 2SD2165 is a single power transistor developed especially
for high h
FE
. This transistor is ideal for simplifying drive circuits and
reducing power dissipation because its h
FE
is as high as that of
Darlington transistors, but it is a single transistor.
In addition, this transistor features a small resin-molded
insulation package, thus contributing to high-density mounting and
mounting cost reduction.
PACKAGE DRAWING (UNIT: mm)
FEATURES
• High h
FE
and low V
CE(sat)
:
h
FE
1,300 TYP. (V
CE
= 5.0 V, I
C
= 1.0 A)
V
CE(SAT)
0.3 V TYP. (I
C
= 3.0 A, I
B
= 30 mA)
• Mold package that does not require an insulating board or
insulation bushing
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
°
Parameter
Collector to base voltage
Collector to emitter voltage
Emitter to base voltage
Collector current (DC)
Collector current (pulse)
Base current (DC)
Total power dissipation
Total power dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
I
B(DC)
P
T
(T
C
= 25°C)
P
T
(T
A
= 25°C)
T
j
T
stg
Ratings
100
100
7.0
6.0
10
Note
1.0
30
2.0
150
−55
to +150
Unit
V
V
V
A
A
A
W
W
°C
°C
Electrode Connection
1. Base
2. Collector
3. Emitter
Note
PW
300
µ
s, duty cycle
10%
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. D13178EJ2V0DS00 (2nd edition)
Date Published April 2002 N CP(K)
Printed in Japan
©
2002
1998
