LC863420B(36DIP) datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> LC863420B(36DIP)

LC863420B(36DIP): DescriptionMicrocontroller, 8-Bit, MROM, 3MHz, CMOS, PDIP36; CategoryThe embedded processor and controller Microcontrollers and processors; File Size529KB，17 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric Compare View All

LC863420B(36DIP) Overview

Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDIP36

LC863420B(36DIP) Parametric

Parameter Name	Attribute value
Maker	SANYO
package instruction	SDIP, SDIP36,.4
Reach Compliance Code	unknown
bit size	8
JESD-30 code	R-PDIP-T36
Number of terminals	36
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SDIP
Encapsulate equivalent code	SDIP36,.4
Package shape	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH
power supply	5 V
Certification status	Not Qualified
RAM (bytes)	384
rom(word)	20480
ROM programmability	MROM
speed	3 MHz
Maximum slew rate	40 mA
Nominal supply voltage	5 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	1.78 mm
Terminal location	DUAL

Preview

Download Datasheet

View All

Ordering number : ENN7935

LC863448B, LC863440B

LC863432B, LC863428B

LC863424B, LC863420B

LC863416B

Overview

CMOS IC

FROM 48K/40K/32K/28K/24K/20K/16K-byte,

RAM 640/512-byte on-chip and 352

9-bit OSD RAM

8-bit 1-chip Microcontroller

The LC863448/40/32/28/24/20/16B are 8-bit single chip microcontrollers with the following on-chip functional blocks :

•

CPU : Operable at a minimum bus cycle time of 0.424µs

•

On-chip ROM capacity

Program ROM : 48K/40K/32K/28K/24K/20K/16K-bytes

CGROM : 16K- bytes

•

On-chip RAM capacity : 640/512-bytes

•

OSD RAM : 352 × 9-bits

•

Closed-Caption TV controller and the on-screen display controller

•

Closed-Caption data slicer

•

Four channels × 6-bit AD Converter

•

Three channels × 7-bit PWM

•

16-bit timer/counter, 14-bit base timer

•

IIC-bus compliant serial interface circuit (Multi-master type)

•

ROM correction function

•

12-source 8-vectored interrupt system

•

Integrated system clock generator and display clock generator

Only one X’tal oscillator (32.768kHz) for PLL reference is used for both generators

TV control and the Closed Caption function

All of the above functions are fabricated on a single chip.

Ver.0.92

62102

73004 JO IM No.7935-1/17

LC863420B(36DIP) Related Products

	LC863420B(36DIP)	LC863432B(36DIP)	LC863432B(36MFP)	LC863420B(36MFP)	LC863440B(36MFP)	LC863440B(36DIP)	LC863428B(36DIP)	LC863428B(36MFP)
Description	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDIP36	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDIP36	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDSO36	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDSO36	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDSO36	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDIP36	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDIP36	Microcontroller, 8-Bit, MROM, 3MHz, CMOS, PDSO36
package instruction	SDIP, SDIP36,.4	SDIP, SDIP36,.4	SSOP, SOP36,.4,32	SSOP, SOP36,.4,32	SSOP, SOP36,.4,32	SDIP, SDIP36,.4	SDIP, SDIP36,.4	SSOP, SOP36,.4,32
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
bit size	8	8	8	8	8	8	8	8
JESD-30 code	R-PDIP-T36	R-PDIP-T36	R-PDSO-G36	R-PDSO-G36	R-PDSO-G36	R-PDIP-T36	R-PDIP-T36	R-PDSO-G36
Number of terminals	36	36	36	36	36	36	36	36
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C
Minimum operating temperature	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SDIP	SDIP	SSOP	SSOP	SSOP	SDIP	SDIP	SSOP
Encapsulate equivalent code	SDIP36,.4	SDIP36,.4	SOP36,.4,32	SOP36,.4,32	SOP36,.4,32	SDIP36,.4	SDIP36,.4	SOP36,.4,32
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH	IN-LINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	IN-LINE, SHRINK PITCH	IN-LINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH
power supply	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	384	384	384	384	512	512	384	384
rom(word)	20480	32768	32768	20480	40960	40960	28672	28672
ROM programmability	MROM	MROM	MROM	MROM	MROM	MROM	MROM	MROM
speed	3 MHz	3 MHz	3 MHz	3 MHz	3 MHz	3 MHz	3 MHz	3 MHz
Maximum slew rate	40 mA	40 mA	40 mA	40 mA	40 mA	40 mA	40 mA	40 mA
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	NO	NO	YES	YES	YES	NO	NO	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	THROUGH-HOLE	GULL WING	GULL WING	GULL WING	THROUGH-HOLE	THROUGH-HOLE	GULL WING
Terminal pitch	1.78 mm	1.78 mm	0.8 mm	0.8 mm	0.8 mm	1.78 mm	1.78 mm	0.8 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maker	SANYO	-	-	SANYO	SANYO	SANYO	SANYO	SANYO
