2SK373
TOSHIBA Field Effect Transistor Silicon N Channel Junction Type
2SK373
For Audio, High Voltage Amplifier and Constant Current
Applications
·
·
High breakdown voltage: V
GDS
=
−100
V (min)
High input impedance: I
GSS
=
−1.0
nA (max) (V
GS
=
−80
V)
Unit: mm
Maximum Ratings
(Ta
=
25°C)
Characteristics
Gate-drain voltage
Gate current
Drain power dissipation
Junction temperature
Storage temperature range
Symbol
V
GDS
I
G
P
D
T
j
T
stg
Rating
-100
10
400
125
-55~125
Unit
V
mA
mW
°C
°C
JEDEC
JEITA
TOSHIBA
TO-92
SC-43
2-5F1C
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Gate cut-off current
Gate-drain breakdown voltage
Drain current
Gate-source cut-off voltage
Forward transfer admittance
Input capacitance
Reverse transfer capacitance
Noise figure
Symbol
I
GSS
V
(BR) GDS
I
DSS
(Note)
V
GS (OFF)
ïY
fs
ï
C
iss
C
rss
NF
Test Condition
V
GS
= -80
V, V
DS
=
0
V
DS
=
0, I
G
= -100 mA
V
DS
=
10 V, V
GS
=
0
V
DS
=
10 V, I
D
=
0.1
mA
V
DS
=
10 V, V
GS
=
0, f
=
1 kHz
V
DS
=
10 V, V
GS
=
0, f
=
1 MHz
V
DG
=
10 V, I
D
=
0, f
=
1 MHz
V
DS
=
10 V, V
GS
=
0, R
G
=
100 kW,
f
=
100 Hz
Weight: 0.21 g (typ.)
Min
¾
-100
0.6
-0.4
1.5
¾
¾
¾
Typ.
¾
¾
¾
¾
4.6
13
3
0.5
Max
-1.0
¾
6.5
-3.5
¾
¾
¾
¾
Unit
nA
V
mA
V
mS
pF
pF
dB
Note: I
DSS
classification
O: 0.6~1.4 mA, Y: 1.2~3.0 mA, GR: 2.6~6.5 mA
1
2003-03-26
