SF19-BP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> SF19-BP

SF19-BP: DescriptionRectifier Diode, 1 Element, 1A, 1000V V(RRM), Silicon, DO-41, PLASTIC PACKAGE-2; CategoryDiscrete semiconductor diode; File Size425KB，4 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric Compare View All

SF19-BP Overview

Rectifier Diode, 1 Element, 1A, 1000V V(RRM), Silicon, DO-41, PLASTIC PACKAGE-2

SF19-BP Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
Parts packaging code	DO-41
package instruction	PLASTIC PACKAGE-2
Contacts	2
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	HIGH RELIABILITY
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	DO-41
JESD-30 code	O-PALF-W2
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	1000 V
Maximum reverse recovery time	0.035 µs
surface mount	NO
Terminal surface	Matte Tin (Sn)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

MCC

Micro Commercial Components

omponents

20736 Marilla Street Chatsworth

!"#

$ % !"#

SF11

Thru

SF19

1.0 Amp Super Fast

Recovery Rectifiers

50 to 1000 Volts

DO-41

•

Features

Fast Switching Speed

Marking : Type Number

Lead Free Finish/RoHS Compliant (Note1) ("P"Suffix designates

Compliant. See ordering information)

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0 and MSL rating 1

•

Maximum Ratings

•

Operating Temperature: -55

℃

to +125℃

Storage Temperature: -55

℃

to +150

℃

Typical Thermal Resistance: 50.0

℃/W

Junction To Ambient

Maximum

Recurrent

Peak Reverse

Voltage

50V

100V

150V

200V

300V

400V

600V

800V

1000V

Maximum

RMS

Voltage

35V

70V

105V

140V

210V

280V

420V

560V

700V

Maximum DC

Blocking

Voltage

50V

100V

150V

200V

300V

400V

600V

800V

1000V

MCC

Part Number

SF11

SF12

SF13

SF14

SF15

SF16

SF17

SF18

SF19

Cathode

Mark

Electrical Characteristics @ 25℃ Unless Otherwise Specified

Average Forward

Current

Peak Forward Surge

Current

Maximum

Instantaneous

Forward Voltage

SF11-SF14

SF15-SF16

SF17-SF19

Maximum DC

Reverse Current At

Rated DC Blocking

Voltage

Maximum Reverse

Recovery Time

Typical Junction

Capacitance

SF11-SF14

SF15-SF19

Note:

F(AV)

FSM

1.0A

30.0A

= 55℃

8.3ms, half sine

0.95V

1.30V

1.70V

5.0uA

100uA

= 1.0A

= 25℃

= 100℃

=0.5A, I

=1.0A,

=0.25A

Measured at

1.0MHz, V

=4.0V

DIM

INCHES

MIN

.166

.080

.028

1.000

DIMENSIONS

MIN

4.10

2.00

.70

25.40

35.0nS

MAX

.205

.107

.034

---

MAX

5.20

2.70

.90

---

NOTE

40pF

25pF

High Temperature Solder Exemption Applied, see EU Directive Annex 7.

www.mccsemi.com

Revision: 5

1 of 4

2008/01/30

SF19-BP Related Products

	SF19-BP	SF19-TP	SF19-AP
Description	Rectifier Diode, 1 Element, 1A, 1000V V(RRM), Silicon, DO-41, PLASTIC PACKAGE-2	Rectifier Diode, 1 Element, 1A, 1000V V(RRM), Silicon, DO-41, PLASTIC PACKAGE-2	Rectifier Diode, 1 Element, 1A, 1000V V(RRM), Silicon, DO-41, PLASTIC PACKAGE-2
Is it lead-free?	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to
Maker	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)
Parts packaging code	DO-41	DO-41	DO-41
package instruction	PLASTIC PACKAGE-2	PLASTIC PACKAGE-2	PLASTIC PACKAGE-2
Contacts	2	2	2
Reach Compliance Code	not_compliant	not_compliant	not_compliant
ECCN code	EAR99	EAR99	EAR99
Other features	HIGH RELIABILITY	HIGH RELIABILITY	HIGH RELIABILITY
Shell connection	ISOLATED	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
JEDEC-95 code	DO-41	DO-41	DO-41
JESD-30 code	O-PALF-W2	O-PALF-W2	O-PALF-W2
JESD-609 code	e3	e3	e3
Humidity sensitivity level	1	1	1
Number of components	1	1	1
Number of terminals	2	2	2
Maximum output current	1 A	1 A	1 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	ROUND	ROUND	ROUND
Package form	LONG FORM	LONG FORM	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	1000 V	1000 V	1000 V
Maximum reverse recovery time	0.035 µs	0.035 µs	0.035 µs
surface mount	NO	NO	NO
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)
Terminal form	WIRE	WIRE	WIRE
Terminal location	AXIAL	AXIAL	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
