MASTER INSTRUMENT CORPORATION
SINGLE-PHASE BRIDGE RECTIFIER
KBPC15005N THRU KBPC1510N
FEATURES
l
Low cost
l
This series is UL recognized under component
index, file number E127707
l
High forward surge current capability
l
Integrally molded heatsink provide very low thermal resistance
l
High isolation voltage from case to lugs
l
High temperature soldering guaranteed:
260
o
C/10 second, at 5 lbs. (2.3kg) tension.
MECHANICAL DATA
l
Case: Molded plastic body
l
Terminal: Lead solderable per MIL-STD-202E
method 208C.
l
Polarity: Polarity symbols molded on case
l
Mounting: Thru hole for #6 screw, 5.0 in.-lbs torque max.
l
Weight:0. 20ounce, 5.62 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.
SYMBOLS
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
15 Amperes
1.13( 28.8)
1.11( 28.2)
0.666( 16.9)
0.626( 15.9)
BR-35N
+
AC
1.13( 28.8)
1.11( 28.2)
0.728( 18.5)
0.688( 17.5)
-
0.666( 16.9)
0.626( 15.9)
AC
0.570( 14.5)
0.530( 13.5)
0.205( 5.2)
0.197( 5.0)
DIA
METAL HEAT SINK
EXOPY CASE
0.32( 8.2)
0.30( 7.8)
0.
2 .3
09 (
IA
) D
0.512( 13.0)
0.413( 10.5)
0.033( 0.84)
0.028( 0.71)
0.252( 6.4)
0.248( 6.3)
0.252( 6.4)
0.248( 6.3)
Dimensions in inches and (millimeters)
KBPC
15005N
KBPC
1501N
KBPC
1502N
KBPC
1504N
KBPC
1506N
KBPC
1508N
KBPC
1510N
UNITS
Volts
Volts
Volts
Amps
Amps
A
2
S
Volts
µAmps
mAmps
V
AC
℃/W
℃
℃
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Output Current, at T
C
=55℃(Note1, 2)
Peak Forward Surge Current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Rating for Fusing(t<8.3ms)
Maximum Instantaneous Forward Voltage at 7.5A
Maximum DC Reverse Current at rated T
A
=25℃
DC blocking voltage
T
A
=150℃
Isolation Voltage from case to leads
Typical Thermal Resistance (Note 1)
Operating Temperature Range
Storage Temperature Range
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
T
V
F
I
R
V
ISO
R
θJC
T
J
T
STG
50
35
50
100
70
100
200
140
200
400
280
400
15
300
373
1.1
10
1.0
2500
2.0
-55 to +150
-55 to +150
600
420
600
800
560
800
1000
700
1000
NOTES:
1.
Unit mounted on 5”×4”×3” thick (12.8mm×10.2mm×7.3mm) Al. plate.
2.
Bolt down on heat-sink with silicone thermal compound between bridge and mounting surface for maximum heat transfer efficiency with #10 screw.
Web Site: WWW.PS-PFS.COM
1/2
