DXM1306-R56

Description
1 ELEMENT, 0.56uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT
CategoryPassive components    inductor
File Size111KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

DXM1306-R56 Overview

1 ELEMENT, 0.56uH, GENERAL PURPOSE INDUCTOR, SMD, ROHS COMPLIANT

DXM1306-R56 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
DC Resistance0.0012 Ω
Nominal inductance(L)0.56 µH
Inductor ApplicationsHIGH CURRENT INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
Manufacturer's serial numberDXM1306
Number of functions1
Number of terminals2
Maximum operating temperature155 °C
Minimum operating temperature-40 °C
Maximum rated current28 A
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
special characteristicsLOW DC RESISTANCE
surface mountYES
Terminal locationDUAL ENDED
Terminal shapeONE SURFACE
Tolerance25%

Preview

Download Datasheet
C orpora te Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
C ircuit Protection Devices
>
Product Feature Selector
> Product Details
DXM1306-R56 Product Details
Live Product Chat
Product View
Magnetics
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
DXM1306-R56
T E I nternal N umber: D XM 1 3 0 6 - R5 6
Product Highlights:
l
Magnetics C ircuit Protection Device
l
Magnetics Device Type = High C urrent Inductor
l
Power Series
l
Surface Mount C ontact Termination Type
l
Inductance = .56 ?H
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Magnetics C ircuit Protection Device
l
Magnetics Device Type = High C urrent Inductor
l
Package = DXM1306
l
Resistance (?) = .0012
Electrical Characteristics:
l
Inductance (?H) = 0.56
l
C urrent Rating (Amps.) = 28
Termination Related Features:
l
Height (mm [in]) = 6.86 [0.270]
Body Related Features:
l
Series = Power
l
Length (mm [in]) = 13.11 [0.516]
l
Width (mm [in]) = 13.08 [0.515]
Contact Related Features:
l
C ontact Termination Type
= Surface Mount
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = C oEv Magnetics
