Datasheet> All Categories > Discrete semiconductor> diode> BAT54A/E8

Preview

BAT54A/E8: DescriptionRectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB,; CategoryDiscrete semiconductor diode; File Size71KB，3 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric Compare View All

BAT54A/E8 Overview

Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB,

BAT54A/E8 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	incompatible
Maker	Vishay
Parts packaging code	SOT-23
package instruction	R-PDSO-G3
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	FAST SWITCHING
Configuration	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.24 V
JEDEC-95 code	TO-236AB
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Maximum non-repetitive peak forward current	0.6 A
Number of components	2
Number of terminals	3
Maximum operating temperature	125 °C
Maximum output current	0.2 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum power dissipation	0.23 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	30 V
Maximum reverse recovery time	0.005 µs
surface mount	YES
technology	SCHOTTKY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	DUAL

Preview

Download Datasheet

View All

BAT54 thru BAT54S

Schottky Diodes

TO-236AB (SOT-23)

.122 (3.1)

.110 (2.8)

.016 (0.4)

3

.056 (1.43

)

.052 (1.33

)

Features

• These diodes feature very low turn-on voltage and

fast switching.

• These devices are protected by a PN junction

guard ring against excessive voltage, such as

electrostatic discharges.

Top View

Mechanical Data

Case:

SOT-23 Plastic Package

Weight:

approx. 0.008g

Packaging Codes/Options:

E8/10K per 13” reel (8mm tape), 30K/box

E9/3K per 7” reel (8mm tape), 30K/box

1

2

max. .004 (0.1)

.007 (0.175)

.005 (0.125)

.037(0.95) .037(0.95)

.016 (0.4)

.102 (2.6)

.094 (2.4)

Dimensions in inches and (millimeters)

.045 (1.15)

.037 (0.95)

Mounting Pad Layout

BAT54A

Marking: L42

BAT54

Marking: L4

Top View

0.031 (0.8)

0.035 (0.9)

BAT54C

Marking: L43

Top View

BAT54S

Marking: L44

0.079 (2.0)

0.037 (0.95)

Maximum Ratings and Thermal Characteristics

Parameter

Repetitive Peak Reverse Voltage

Forward Continuous Current at T

amb

= 25°C

Repetitive Peak Forward Current at T

amb

= 25°C

Surge Forward Current at t

p

< 1 s, T

amb

= 25°C

Power Dissipation at T

amb

= 25°C

Thermal Resistance Junction to Ambiant Air

Junction Temperature

Storage Temperature Range

Note:

(1) Device on fiberglass substrate, see layout on next page.

(T

A

= 25°C unless otherwise noted)

Symbol

V

RRM

I

F

I

FRM

I

FSM

P

tot

R

θJA

T

j

T

S

Value

30

200

(1)

300

(1)

600

(1)

230

430

(1)

150

–65 to +150

Unit

V

mA

mW

°C/W

°C

4/19/01

BAT54A/E8 Related Products

	BAT54A/E8	BAT54S/E8	BAT54S/E9	BAT54C/E8	BAT54/E8	BAT54A/E9	BAT54C/E9	BAT54/E9
Description	Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB,	Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB	Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB	Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB,	Rectifier Diode, Schottky, 1 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB	Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB,	Rectifier Diode, Schottky, 2 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB,	Rectifier Diode, Schottky, 1 Element, 0.2A, 30V V(RRM), Silicon, TO-236AB
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
package instruction	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	FAST SWITCHING	FAST SWITCHING	FAST SWITCHING	FAST SWITCHING	FAST SWITCHING	FAST SWITCHING	FAST SWITCHING	FAST SWITCHING
Configuration	COMMON ANODE, 2 ELEMENTS	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS	SINGLE	COMMON ANODE, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	0.24 V	0.24 V	0.24 V	0.24 V	0.24 V	0.24 V	0.24 V	0.24 V
JEDEC-95 code	TO-236AB	TO-236AB	TO-236AB	TO-236AB	TO-236AB	TO-236AB	TO-236AB	TO-236AB
JESD-30 code	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3
JESD-609 code	e0	e0	e0	e0	e0	e0	e0	e0
Maximum non-repetitive peak forward current	0.6 A	0.6 A	0.6 A	0.6 A	0.6 A	0.6 A	0.6 A	0.6 A
Number of components	2	2	2	2	1	2	2	1
Number of terminals	3	3	3	3	3	3	3	3
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Maximum output current	0.2 A	0.2 A	0.2 A	0.2 A	0.2 A	0.2 A	0.2 A	0.2 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Maximum power dissipation	0.23 W	0.23 W	0.23 W	0.23 W	0.23 W	0.23 W	0.23 W	0.23 W
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	30 V	30 V	30 V	30 V	30 V	30 V	30 V	30 V
Maximum reverse recovery time	0.005 µs	0.005 µs	0.005 µs	0.005 µs	0.005 µs	0.005 µs	0.005 µs	0.005 µs
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
technology	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maker	Vishay	-	-	-	Vishay	Vishay	Vishay	Vishay
Parts packaging code	SOT-23	SOT-23	SOT-23	SOT-23	SOT-23	-	-	-
Contacts	3	3	3	3	3	-	-	-
