MLAS100-10: DescriptionBoard Connector, 10 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,; CategoryThe connector The connector; File Size172KB，1 Pages; ManufacturerITW Switches

Download Datasheet Parametric Compare View All

MLAS100-10 Overview

Board Connector, 10 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,

MLAS100-10 Parametric

Parameter Name	Attribute value
Maker	ITW Switches
Reach Compliance Code	compliant
Other features	POLARIZED
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	ML
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	10

Preview

Download Datasheet

View All

MAS-CON

®

d

Serie MLSS/MLAS 100

u

Series MLSS/MLAS 100

d

2- bis 12- und 14-polige Stiftleisten im Raster 2,54 mm.

Seitenpolarisierung und Verriegelung.

u

2.54 mm Headers available in 2 – 12 and 14 circuits.

Tab polarisation and locking.

f

Série MLSS/MLAS 100

i

Serie MLSS/MLAS 100

f

Connecteurs mâles au pas de 2,54 mm

de 2 à 12 et 14 points.

Polarisation au pas et verrouillage

i

Passo 2,54 mm. Connettori di testa disponibili

da 2 a 12 et 14 contatti.

Polarizzazione laterale i con blocco.

54

2,

.100

"

mm

3,3

1,42 max.

90° 7,5

3,0

3,6

6,9

MLAS 100 - ...

9,4

0,64

1,42 max.

7,9

2,8

3,6

3,3

6,9

MLSS 100 - …

9,4

Abmessungen /

Dimensions

/

Dimensions

/

Dimensioni

2

(mm)

a

3

4

5

6

7

8

9

10

Polzahl /

No. of Circuits

/

Nombre de circuits

/

No. Poli

11 12 13 14 15 16 17 18 19 20

—

21

—

22

—

23

—

24

—

25

—

26

—

27

—

28

—

5,08 7,62 10,16 12,70 15,24 17,78 20,32 22,86 25,40 27,94 30,48 — 35,56 —

Bestell-Nummern

3)

/

Part Number

3)

/

Références

3)

/

Codice Prodotto

3)

Polzahl /

No. of Circuits

/

Nombre de circuits

/

No. Poli

2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14

Ausführung /

Description

/

Désignation

/

Descrizione

Gerade mit Seitenpolarisierung und Verriegelung

Abgewinkelt mit Seitenpolarisierung und Verriegelung

Straight with Tab Polarization and Locking

Angled with Tab Polarization and Locking

Droit avec Polarisation au pas et verrouillage

Coudé avec Polarisation au pas et verrouillage

Diritto con polarizzazione laterale e con blocco

Piegato con polarizzazione laterale e con blocco

MLSS100-

3)

d

Hinweise siehe Seite 31

u

Notes see page 31

MLAS100-

3)

f

Note voir la page 31

i

Note vedi pagina 31

15

MLAS100-10 Related Products

	MLAS100-10	MLAS100-11	MLAS100-12	MLAS100-14	MLAS100-03	MLAS100-04
Description	Board Connector, 10 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,	Board Connector, 11 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,	Board Connector, 12 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,	Board Connector, 14 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,	Board Connector, 3 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,	Board Connector, 4 Contact(s), 1 Row(s), Male, Right Angle, Solder Terminal,
Maker	ITW Switches	ITW Switches	ITW Switches	ITW Switches	ITW Switches	ITW Switches
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
Other features	POLARIZED	POLARIZED	POLARIZED	POLARIZED	POLARIZED	POLARIZED
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Contact point gender	MALE	MALE	MALE	MALE	MALE	MALE
DIN compliance	NO	NO	NO	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	NO
Manufacturer's serial number	ML	ML	ML	ML	ML	ML
Mixed contacts	NO	NO	NO	NO	NO	NO
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of rows loaded	1	1	1	1	1	1
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Termination type	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER
Total number of contacts	10	11	12	14	3	4
