5962F9672401VXC datasheet, PDF

Datasheet> All Categories > logic> logic> 5962F9672401VXC

5962F9672401VXC: DescriptionDUAL 4-BIT DRIVER, TRUE OUTPUT, CERAMIC, FP-20; Categorylogic logic; File Size44KB，4 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

5962F9672401VXC Overview

DUAL 4-BIT DRIVER, TRUE OUTPUT, CERAMIC, FP-20

5962F9672401VXC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	DFP
package instruction	DFP, FL20,.3
Contacts	20
Reach Compliance Code	not_compliant
series	ACT
JESD-30 code	R-CDFP-F20
JESD-609 code	e0
Load capacitance (CL)	50 pF
Logic integrated circuit type	BUS DRIVER
MaximumI(ol)	0.008 A
Number of digits	8
Number of functions	1
Number of ports	2
Number of terminals	20
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output characteristics	3-STATE
Output polarity	TRUE
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP
Encapsulate equivalent code	FL20,.3
Package shape	RECTANGULAR
Package form	FLATPACK
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	5 V
Prop。Delay @ Nom-Sup	17 ns
propagation delay (tpd)	17 ns
Certification status	Not Qualified
Filter level	MIL-PRF-38535 Class V
Maximum seat height	2.92 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
total dose	300k Rad(Si) V
width	6.92 mm

Preview

Download Datasheet

View All

ACS573MS

January 1996

Radiation Hardened Octal

Three-State Transparent Latch

Pinouts

20 LEAD CERAMIC DUAL-IN-LINE

MIL-STD-1835 DESIGNATOR,

CDIP2-T20, LEAD FINISH C

TOP VIEW

20 VCC

19 Q0

18 Q1

17 Q2

16 Q3

15 Q4

14 Q5

13 Q6

12 Q7

11 LE

Features

• Devices QML Qualiﬁed in Accordance with MIL-PRF-38535

• Detailed Electrical and Screening Requirements are Contained in

SMD# 5962-96724 and Intersil’s QM Plan

• 1.25 Micron Radiation Hardened SOS CMOS

• Total Dose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >300K RAD (Si)

• Single Event Upset (SEU) Immunity: <1 x 10

-10

Errors/Bit/Day

(Typ)

• SEU LET Threshold . . . . . . . . . . . . . . . . . . . . . . . >100 MEV-cm

/mg

• Dose Rate Upset . . . . . . . . . . . . . . . . >10

RAD (Si)/s, 20ns Pulse

• Dose Rate Survivability . . . . . . . . . . . >10

RAD (Si)/s, 20ns Pulse

• Latch-Up Free Under Any Conditions

• Military Temperature Range . . . . . . . . . . . . . . . . . . -55

C to +125

• Signiﬁcant Power Reduction Compared to ALSTTL Logic

• DC Operating Voltage Range . . . . . . . . . . . . . . . . . . . . 4.5V to 5.5V

• Input Logic Levels

- VIL = 30% of VCC Max

- VIH = 70% of VCC Min

• Input Current

≤

1µA at VOL, VOH

• Fast Propagation Delay . . . . . . . . . . . . . . . . 17ns (Max), 12ns (Typ)

GND 10

20 LEAD CERAMIC FLATPACK

MIL-STD-1835 DESIGNATOR,

CDFP4-F20, LEAD FINISH C

TOP VIEW

Description

VCC

The Intersil ACS573MS is a Radiation Hardened Octal Transparent

Latch with an active low output enable. The outputs are transparent to

the inputs when the latch enable (LE) is High. When the latch goes low

the data is latched. The output enable controls the three-state outputs.

When the output enable pins (OE) are high the output is in a high

impedance state. The latch operation is independent of the state of

output enable.

The ACS573MS utilizes advanced CMOS/SOS technology to achieve

high-speed operation. This device is a member of a radiation hardened,

high-speed, CMOS/SOS Logic family.

The ACS573MS is supplied in a 20 lead Ceramic Flatpack (K sufﬁx) or a

GND

Ordering Information

PART NUMBER

5962F9672401VRC

5962F9672401VXC

ACS573D/Sample

ACS573K/Sample

ACS573HMSR

TEMPERATURE RANGE

-55

C to +125

-55

C to +125

SCREENING LEVEL

MIL-PRF-38535 Class V

Sample

Die

PACKAGE

20 Lead SBDIP

20 Lead Ceramic Flatpack

20 Lead SBDIP

20 Lead Ceramic Flatpack

Die

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

Spec Number

518893

File Number

4093

5962F9672401VXC Related Products

	5962F9672401VXC	5962F9672401VRC
Description	DUAL 4-BIT DRIVER, TRUE OUTPUT, CERAMIC, FP-20	DUAL 4-BIT DRIVER, TRUE OUTPUT, SIDE BRAZED, DIP-20
Is it Rohs certified?	incompatible	incompatible
Maker	Renesas Electronics Corporation	Renesas Electronics Corporation
Parts packaging code	DFP	DIP
package instruction	DFP, FL20,.3	CERAMIC, DIP-20
Contacts	20	20
Reach Compliance Code	not_compliant	not_compliant
series	ACT	ACT
JESD-30 code	R-CDFP-F20	R-CDIP-T20
JESD-609 code	e0	e0
Load capacitance (CL)	50 pF	50 pF
Logic integrated circuit type	BUS DRIVER	BUS DRIVER
MaximumI(ol)	0.008 A	0.008 A
Number of digits	8	8
Number of functions	1	1
Number of ports	2	2
Number of terminals	20	20
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C
Output characteristics	3-STATE	3-STATE
Output polarity	TRUE	TRUE
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP	DIP
Encapsulate equivalent code	FL20,.3	DIP20,.3
Package shape	RECTANGULAR	RECTANGULAR
Package form	FLATPACK	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
power supply	5 V	5 V
Prop。Delay @ Nom-Sup	17 ns	17 ns
propagation delay (tpd)	17 ns	17 ns
Certification status	Not Qualified	Not Qualified
Filter level	MIL-PRF-38535 Class V	MIL-PRF-38535 Class V
Maximum seat height	2.92 mm	5.08 mm
Maximum supply voltage (Vsup)	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	5 V
surface mount	YES	NO
technology	CMOS	CMOS
Temperature level	MILITARY	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	FLAT	THROUGH-HOLE
Terminal pitch	1.27 mm	2.54 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
total dose	300k Rad(Si) V	300k Rad(Si) V
width	6.92 mm	7.62 mm
