836119016: Description9 CONTACT(S), MALE, D SUBMINIATURE CONNECTOR, SOLDER; CategoryThe connector The connector; File Size110KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

836119016 Overview

9 CONTACT(S), MALE, D SUBMINIATURE CONNECTOR, SOLDER

836119016 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Molex
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
Connector type	D SUBMINIATURE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation type	BOARD AND PANEL
Options	GENERAL PURPOSE
Housing size	1/E
Termination type	SOLDER
Total number of contacts	9
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 05/20/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

0836119016

Active

commercial_microd

1.27mm (.050") Pitch Commercial Micro-D, PCB Mount, Right Angle Plug, without

Jackposts, 9 Circuits

Documents:

3D Model

Drawing (PDF)

Product Specification PS-83421-001 (PDF)

RoHS Certificate of Compliance (PDF)

General

Product Family

Series

Application

Comments

Component Type

Overview

Product Literature Order No

Product Name

Type

I/O Connectors

83611

Wire-to-Board

83041-0005 Jackposts can be purchased separately

Plug

commercial_microd

USA-063

Commercial Micro-D

N/A

Physical

Circuits (Loaded)

Circuits (maximum)

Durability (mating cycles max)

Lock to Mating Part

Material - Plating Mating

Orientation

PC Tail Length (in)

PC Tail Length (mm)

PCB Retention

PCB Thickness Recommended (in)

PCB Thickness Recommended (mm)

Packaging Type

Panel Mount

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Polarized to Mating Part

Surface Mount Compatible (SMC)

Temperature Range - Operating

Termination Interface: Style

Wire Size AWG

500

None

Gold

Right Angle

0.110 In

2.79 mm

Yes

0.060 In

1.52 mm

Tube

Yes

0.050 In

1.27 mm

0.38

Yes

-40°C to +125°C

Through Hole

N/A

EU RoHS

ELV and

Complia

REACH S

Contains

Halogen

Status

Not Revi

Need mo

environm

Email pro

For a mu

Complian

Please vi

non-prod

83611S

Mates

83421

Electrical

Current - Maximum per Contact

Shielded

Voltage - Maximum

Yes

350V AC

Material Info

Reference - Drawing Numbers

Product Specification

Sales Drawing

PS-83421-001

SD-83611-002

Recommended Resources
