Subminiature
Shielded Inductors
.335"
24 AWG/TCW
LS2B
.132"
1.15"nominal
These reliable subminiature shielded inductors are especially suited for high-density applications. All feature magnetic
shielding, excellent inductance-to-size ratios, low DC resistance and high Q.
INDUCTANCES 0.10µH to 1,000µH
OPERATING TEMPERATURE RANGE -55°C to +105°C
CURRENT RATING Based on 0.25 w power dissipation.
att
INDUCTANCE TOLERANCE ±10% o
ver entire inductance
range. (Special values and tighter tolerances available upon
request.)
SHIELDING 5% coupling maxim
um with 2 units side by side
at 1KHz.
TESTING Inductance and Q measured with Q meter HP4342A
at specified frequency. DCR measured with Milliohm meter.
SRF measured on 159 Grid Dip meter.
MARKING 5-Band Color Code.
PACKAGING Bulk or Tape and Reel.
PART
NUMBER
LS2B-R10K
LS2B-R12K
LS2B-R15K
LS2B-R18K
LS2B-R22K
LS2B-R27K
LS2B-R33K
LS2B-R39K
LS2B-R47K
LS2B-R65K
LS2B-R68K
LS2B-R82K
LS2B-1R0K
LS2B-1R2K
LS2B-1R5K
LS2B-1R8K
LS2B-2R2K
LS2B-2R7K
LS2B-3R3K
LS2B-3R9K
LS2B-4R7K
LS2B-5R6K
LS2B-6R8K
LS2B-8R2K
LS2B-100K
LS2B-120K
LS2B-150K
LS2B-180K
LS2B-220K
LS2B-270K
LS2B-330K
LS2B-390K
LS2B-470K
LS2B-560K
LS2B-680K
LS2B-820K
LS2B-101K
LS2B-121K
LS2B-151K
LS2B-181K
LS2B-221K
LS2B-271K
LS2B-331K
LS2B-391K
LS2B-471K
LS2B-561K
LS2B-681K
LS2B-821K
LS2B-102K
INDUCTANCE
(µH)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.65
.68
.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Q
MINIMUM
42
42
42
42
42
42
42
42
41
39
36
35
42
38
38
38
36
38
38
40
42
42
45
47
51
51
45
43
42
37
46
38
42
41
46
46
43
50
49
56
53
57
57
57
50
50
56
49
49
TEST
FREQUENCY
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
SELF RESONANT
FREQUENCY
MINIMUM (MHz)
500
500
500
336
331
298
288
271
247
236
216
200
136
120
111
103
94.0
84.8
78.4
72.8
66.4
61.6
54.6
49.6
44.0
39.2
44.0
40.0
36.0
32.8
29.6
26.4
23.2
21.6
18.4
16.8
15.2
14.4
12.0
11.2
9.6
9.2
8.4
8.0
6.8
6.0
5.6
5.2
4.8
DC RESISTANCE
OHMS
MAXIMUM (Ω )
.112
.126
.136
.165
.198
.220
.258
.292
.360
.397
.472
.638
.208
.225
.265
.285
.330
.381
.432
.576
.787
1.040
1.400
1.680
2.580
3.650
0.862
1.020
1.120
1.280
1.700
1.990
2.410
2.850
3.210
3.570
4.100
5.970
7.050
8.120
14.800
16.800
18.600
21.100
32.200
36.400
41.100
45.000
52.000
RATED DC
CURRENT MAX
(mA)
1720
1630
1550
1420
1330
1230
1140
1060
960
915
840
720
1260
1210
1120
1080
1000
935
875
755
650
565
485
440
355
300
620
570
545
510
440
405
370
340
320
305
280
235
215
200
150
140
130
120
100
95
90
85
80
