SMV2113-15: DescriptionVariable Capacitance Diode, 68pF C(T), 30V, Silicon, Abrupt, TO-92, PLASTIC, CASE 182-02, TMV, TO-92, 2 PIN; CategoryDiscrete semiconductor diode; File Size33KB，1 Pages; ManufacturerCobham Semiconductor Solutions; Environmental Compliance

Download Datasheet Parametric View All

SMV2113-15 Overview

Variable Capacitance Diode, 68pF C(T), 30V, Silicon, Abrupt, TO-92, PLASTIC, CASE 182-02, TMV, TO-92, 2 PIN

SMV2113-15 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Cobham Semiconductor Solutions
Parts packaging code	TO-92
package instruction	O-PBCY-T2
Contacts	3
Manufacturer packaging code	CASE 182-02
Reach Compliance Code	unknown
ECCN code	EAR99
Minimum breakdown voltage	30 V
Configuration	SINGLE
Diode Capacitance Tolerance	10%
Minimum diode capacitance ratio	2.6
Nominal diode capacitance	68 pF
Diode component materials	SILICON
Diode type	VARIABLE CAPACITANCE DIODE
JEDEC-95 code	TO-92
JESD-30 code	O-PBCY-T2
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.25 W
Certification status	Not Qualified
minimum quality factor	150
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
Varactor Diode Classification	ABRUPT

Preview

Download Datasheet

View All

PLASTIC SURFACE MOUNT

GENERAL PURPOSE ABRUPT VARACTOR DIODES

SMV2101 - SMV2115

PART

NUMBER

♦ ♦♦

SMV2101

SMV2102

SMV2103

SMV2104

SMV2105

SMV2106

SMV2107

SMV2108

SMV2109

SMV2110

SMV2111

SMV2112

SMV2113

SMV2114

SMV2115

CAPACITANCE

@ 4 Vdc

f = 1 MHz (pF)

6.8

8.2

10.0

12.0

15.0

18.0

22.0

27.0

33.0

39.0

47.0

56.0

68.0

82.0

100.0

MIN QUALITY FACTOR CAPACITANCE RATIO

Q @ 4 Vdc

f = 1 MHZ C•2V / C•30V

f = 50 MHz

MIN

450

2.5

450

2.5

400

2.5

400

2.5

400

2.5

350

2.5

350

2.5

300

2.5

200

2.5

150

2.5

150

2.5

150

2.6

150

2.6

100

2.6

100

2.6

AVAILABLE

IN THE FOLLOWING

PACKAGES

-01, -08, -15

-01, -09, -15

DC Power Dissipation

Reverse Breakdown Voltage

Max Reverse Current (I

R

)

Operating Temperature (Topr)

Storage Temperature (Tstg)

Capacitance Tolerance:

@ Ta = 25°C

@ 10µA

@ Ta = 25° C

250 mW

30 V Min

0.1 µA @ 25 Vdc

-55 to + 125° C

-65 to + 150° C

±10%

♦♦♦

Package Styles

Requires adding a dash suffix number to the part number

SOT23 SINGLE

SOT23 Common Anode

TO-92 Two Terminal (TMV)

CHIPS

-08

-09

-15

-01
