Part Number:
Status:
Description:
0767156108
Active
1.40mm (0.055") Pitch Tinman Right Angle, Dual End, 5 Pair, 8 Column, 120 Circuits,
85 Ohms, Tin/Lead
Documents:
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
General
Product Family
Series
Application
Comments
Component Type
Product Name
Style
Backplane Connectors
76715
Backplane
85 Ohms
PCB Receptacle
Tinman
N/A
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Resin
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
120
120
Black
200
Yes
No
None
Copper Alloy
Tin-Lead
High Temperature Thermoplastic
8
5
15
Right Angle
0.098 In
2.50 mm
No
None
0.055 In
1.40 mm
Tube
0.074 In
1.90 mm
No
Yes
-65°C to +90°C
Surface Mount
EU RoHS
RoHS Co
Exemptio
REACH S
Not Revi
Halogen
Status
Not Revi
Need mo
environm
Email pro
For a mu
Complian
Please vi
non-prod
Search
76715S
Electrical
Current - Maximum per Contact
Data Rate
Shielded
Voltage - Maximum
0.5A
10.0 Gbps
No
250V AC
Material Info
Reference - Drawing Numbers
Packaging Specification
Sales Drawing
PK-70873-0064
SD-76715-608
