AD7376ARU1M-REEL7

Description
IC 1000K DIGITAL POTENTIOMETER, 3-WIRE SERIAL CONTROL INTERFACE, 128 POSITIONS, PDSO14, TSSOP-14, Digital Potentiometer
CategoryAnalog mixed-signal IC    converter
File Size265KB,12 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric View All

AD7376ARU1M-REEL7 Overview

IC 1000K DIGITAL POTENTIOMETER, 3-WIRE SERIAL CONTROL INTERFACE, 128 POSITIONS, PDSO14, TSSOP-14, Digital Potentiometer

AD7376ARU1M-REEL7 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerADI
Parts packaging codeTSSOP
package instructionTSSOP-14
Contacts14
Reach Compliance Codenot_compliant
ECCN codeEAR99
Other featuresREST 3 RESISTOR ARRAY VALUES ARE : 10000,50000,100000 OHMS
Nominal bandwidth0.6 kHz
control interface3-WIRE SERIAL
Converter typeDIGITAL POTENTIOMETER
JESD-30 codeR-PDSO-G14
JESD-609 codee0
length5 mm
Humidity sensitivity level1
Nominal negative supply voltage-4.5 V
Number of positions128
Number of terminals14
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeTSSOP
Encapsulate equivalent codeTSSOP14,.25
Package shapeRECTANGULAR
Package formSMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)240
power supply+-5/+-15 V
Certification statusNot Qualified
resistance lawLINEAR
Maximum seat height1.2 mm
Nominal supply voltage5 V
surface mountYES
Temperature levelINDUSTRIAL
Terminal surfaceTin/Lead (Sn85Pb15)
Terminal formGULL WING
Terminal pitch0.65 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Nominal total resistance1000000 Ω
width4.4 mm
a
FEATURES
128 Position
Potentiometer Replacement
10 k , 50 k , 100 k , 1 M
Power Shutdown: Less than 1 A
3-Wire SPI Compatible Serial Data Input
+5 V to +30 V Single Supply Operation
5 V to 15 V Dual Supply Operation
Midscale Preset
APPLICATIONS
Mechanical Potentiometer Replacement
Instrumentation: Gain, Offset Adjustment
Programmable Voltage-to-Current Conversion
Programmable Filters, Delays, Time Constants
Line Impedance Matching
Power Supply Adjustment
GENERAL DESCRIPTION
SDO
15 V Operation
Digital Potentiometer
AD7376*
FUNCTIONAL BLOCK DIAGRAM
AD7376
Q
7-BIT
SERIAL
REGISTER
SDI
CLK
CS
D
CK
7
7-BIT
LATCH
R
7
V
DD
A
W
B
SHDN
V
SS
GND
RS
SHDN
The AD7376 provides a single channel, 128-position digitally-
controlled variable resistor (VR) device. This device performs the
same electronic adjustment function as a potentiometer or vari-
able resistor. These products were optimized for instrument and
test equipment applications where a combination of high voltage
with a choice between bandwidth or power dissipation are avail-
able as a result of the wide selection of end-to-end terminal resis-
tance values. The AD7376 contains a fixed resistor with a wiper
contact that taps the fixed resistor value at a point determined by
a digital code loaded into the SPI-compatible serial-input regis-
ter. The resistance between the wiper and either endpoint of the
fixed resistor varies linearly with respect to the digital code trans-
ferred into the VR latch. The variable resistor offers a completely
programmable value of resistance between the A terminal and the
wiper or the B terminal and the wiper. The fixed A to B terminal
resistance of 10 kΩ, 50 kΩ, 100 kΩ or 1 MΩ has a nominal tem-
perature coefficient of –300 ppm/°C.
The VR has its own VR latch which holds its programmed resis-
tance value. The VR latch is updated from an internal serial-to-
parallel shift register which is loaded from a standard 3-wire
serial-input digital interface. Seven data bits make up the data
word clocked into the serial data input register (SDI). Only the
last seven bits of the data word loaded are transferred into the
7-bit VR latch when the
CS
strobe is returned to logic high. A
serial data output pin (SDO) at the opposite end of the serial
register allows simple daisy-chaining in multiple VR applications
without additional external decoding logic.
The reset (RS) pin forces the wiper to the midscale position by
loading 40
H
into the VR latch. The
SHDN
pin forces the resistor
*Patent
Number: 5495245
to an end-to-end open circuit condition on the A terminal and
shorts the wiper to the B terminal, achieving a microwatt power
shutdown state. When shutdown is returned to logic high, the
previous latch settings put the wiper in the same resistance
setting prior to shutdown as long as power to V
DD
is not re-
moved. The digital interface is still active in shutdown so that
code changes can be made that will produce a new wiper posi-
tion when the device is taken out of shutdown.
The AD7376 is available in both surface mount (SOL-16) and
the 14-lead plastic DIP package. For ultracompact solutions
selected models are available in the thin TSSOP package. All
parts are guaranteed to operate over the extended industrial
temperature range of –40°C to +85°C. For operation at lower
supply voltages (+3 V to +5 V), see the AD8400/AD8402/
AD8403 products.
SDI
(DATA IN)
1
0
D
X
D
X
t
DS
t
DH
SDO
(DATA OUT)
1
D'
X
0
D'
X
t
PD_MAX
t
CH
1
CLK
0
t
CS1
t
CL
t
CSS
t
CSH
t
CSW
t
S
t
CSH0
1
CS
0
V
OUT
V
DD
0V
1 LSB ERROR BAND
1 LSB
Figure 1. Detail Timing Diagram
The last seven data bits clocked into the serial input register will
be transferred to the VR 7-bit latch when
CS
returns to logic
high. Extra data bits are ignored.
REV. 0
Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Analog Devices.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781/329-4700
World Wide Web Site: http://www.analog.com
Fax: 781/326-8703
© Analog Devices, Inc., 1997
