• Available with dimples to aid in EMI/ESD protection
• Improved metal strain relief hooks directly to metal
shell
• Low profile
• Four mounting options
• RoHS Compliant. See the Regulatory Information
Appendix (RIA) in the "RoHS Compliance" section
of www.3Mconnector.com for compliance
information (RIA E1 and C1 apply).
Date Modified: February 15, 2010
TS-0234-D
Sheet 1 of 3
Physical
Insulation:
Material: Glass Filled Polyester (PBT)
Flammability: UL 94V-0
Color: Gray
Contact:
Material: Copper Alloy
Plating:
Underplating: 100 µ" [ 2.54 µm ] Nickel
Wiping Area: 30 µ" [ 0.76 µm ] Gold
Shell Material:
Steel
Plating: Tin
Strain Relief Material:
Stainless Steel .016 [ 0.40 ] Thick
Wire Accommodation:
26 and 28 AWG Solid or Stranded
Marking:
3M Logo and Contact Position Numbers
Electrical
Current Rating:
1 A
Insulation Resistance:
> 1 × 10
9
Ω
at 500 V
DC
Withstanding Voltage:
1000 V
RMS
at Sea Level
Environmental
Temperature Rating:
-55°C to +105°C
UL File No.: E68080
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnector.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
D Sub Plug
Plug Connector
8200 Series
Contact
Quantity
9
15
25
37
Dimensions
A
1.22 [30.9]
1.54 [39.2]
2.09 [53.0]
2.73 [69.4]
B
0.67 [16.9]
1.00 [25.4]
1.54 [39.1]
2.18 [55.43]
C
0.98 [25.0]
1.31 [33.3]
1.85 [47.0]
2.50 [63.5]
D
0.46 [11.75]
0.76 [19.4]
1.27 [32.2]
1.87 [47.6]
E
0.67 [16.92]
0.99 [25.2]
1.54 [39.0]
2.19 [55.56]
F ± .008
0.70 [17.76]
1.03 [26.15]
1.58 [40.1]
2.22 [56.34]
E
D
Closed End
Cover
.050 Typ
[ 1.27 ]
Note: Number and
location of dimples
varies by part size.
Open End
Cover 1
Adhesive w/Liner
.65
[ 16.5 ]
Assembled
Thickness
.384
[ 9.75 ]
.42 Ref
[ 10.7 ]
.24 +.00
[ 6.0 ] -.01
A
See Page
3 Details
.0545 Typ
[ 1.384 ]
Position 1
.11 Ref
[ 2.8 ]
.49
[ 12.4 ]
1
2
3
4
5
6
7
9
10
11
12
13
C
.295
[ 7.5 ]
Note: dimension taken from
inside of dimple on inside of
shell.
14
15
16
17
18
20
21
22
23
24
25
10° Typ
B
C
Inch
[mm]
Tolerance Unless Noted
Inch
.0
±.1
.00
±.01
.000
±.005
[ ] Dimensions for Reference Only
Ordering Information
Connector
82XX - X00X
Contact
Quantity
Cover Style:
6= Open Cover
7= Closed Cover
Mounting Style:
0 =
Ø
.120 [ 3.05 ]
(E1 & C1 Apply)
3 = 4-40 UNC
(E5 & C3 Apply)
9 = Rivet Crimp
(E1 & C1 Apply)
Strain Relief
(Order Separately)
3448 - 8DXXA
09 = 9 Position
15 = 15 Position
25 = 25 Position
37 = 37 Position
TS-0234-D
Sheet 2 of 3
Assembly tools: 3M™ Press, 3640 (or equivalent), 3M™ Locator Plate, 3443-106N, 3M™ Platen, 3442-39N for (9 & 15 pos.) or 3442-41N for (25 & 37 pos.)
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnector.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
D Sub Plug
Plug Connector
Mounting
Method*
Contact
Quantity
9
15
Front
25
37
9
15
Rear
25
37
Dimensions
A1
.87
[ 22.1 ]
1.20
[ 30.5 ]
1.74
[ 44.2 ]
2.39
[ 60.7 ]
0.81
[ 20.6 ]
1.13
[ 28.7 ]
1.67
[ 42.4 ]
2.33
[ 59.2 ]
B1
.44
[ 11.2 ]
.60
[ 15.2 ]
.87
[ 22.1 ]
1.20
[ 30.5 ]
.40
[ 10.2 ]
.57
[ 14.5 ]
.84
[ 21.3 ]
1.16
[ 29.5 ]
C1
.98
[ 24.9 ]
1.31
[ 33.3 ]
1.85
[ 47.0 ]
2.50
[ 63.5 ]
.98
[ 25.0 ]
1.31
[ 33.3 ]
1.85
[ 47.0 ]
2.50
[ 63.5 ]
D1
.49
[ 12.5 ]
.66
[ 16.8 ]
.93
[ 23.6 ]
1.25
[ 31.8 ]
.49
[ 12.5 ]
.66
[ 16.8 ]
.93
[ 23.6 ]
1.25
[ 31.8 ]
0.45
[11.4]
0.22
[5.6]
.12
[3.0]
.51
[13.0]
.26
[6.6]
.12
[3.0]
E1
F1
G1
8200 Series
Front Mount-The connector is mounted in front of the panel.
Rear Mount-The connector is mounted behind the panel.
Panel Cutout
A1
B1
10° 0° Typ
R .032 Max. Typ
[ 0.81 ]
.120
[ 3.05 ]
F1
E1
.060
[ 1.52 ]
Full Radius
D1
C1
Alternate
GI Radius
Typ
Mounting Styles
Standard
.12
[ 3.0 ]
Dia
Through Hole
Strain Relief
(Order Separately)
Material: Stainless Steel
.07 Max
[ 1.78 ]
Threaded Inserts
F
#4-40 UNC
+.000
.242 -.010
[ 6.15 ]
.12
[ 3.0 ]
.06
[ 1.5 ]
.16
[ 4.06 ]
TS-0234-D
Sheet 3 of 3
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnector.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
