F-211
IPL1–105–02–L–D–K
IPL1–120–01–L–D–RA–K
IPL1–110–02–L–S–K
(2,54mm) .100"
IPL1 SERIES
SHROUDED POWER CABLE HEADER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?IPL1
Insulator Material:
Natural LCP
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over 50µ"
(1,27µm) Ni
Operating Temp Range:
-55°C to +125°C
Voltage Rating:
675 VAC/954 VDC
RoHS Compliant:
Yes
Mates with:
MMSD, MMSS,
IPD1, SCR2
(Does not mate with IPS1)
Mates with discrete wire
cable assemblies
(IPD1 & MMSD Series)
Keyed
Polarization
Surface Mount,
Right Angle and
Vertical Through-hole
Align &
Latch™
Processing:
Lead–Free Solderable:
Yes
–S & –D
SMT Lead Coplanarity:
(0,10mm) .004" max (02-05)
(0,13mm) .005" max (06-10)
(0,15mm) .006" max (11-25)
–DH
SMT Lead Coplanarity:
(0,254mm) .010" max
CURRENT RATING
SCP2/SCR2/
AMBIENT
MMSD/IPL1
IPL1
TEMP
7.4A
5A
20°C
6.5A
4.2A
40°C
5.9A
3.5A
60°C
N/A
2.8A
75°C
3.8A
N/A
95°C
6 POSITIONS (2x3) 20 AWG POWERED
• Individually
shrouded pins
(2,54mm)
.100" pitch
• Align & Latch
TM
System
IPL1
APPLICATION
SPECIFIC
OPTIONS
• With or without Plug
Polarization.
• Guide post holes
Call Samtec.
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OPTION
K
–01
02, 05, 10,
15, 16, 20, 25
(Call Samtec for other sizes)
01
–L
= 10µ"
(0,25µm)
Gold on
contact,
Matte Tin
on tail
25
–S
= Single Row
Vertical
–RA
=Right
Angle
(–01 lead
style only)
= Through-
hole
–K
=Keyed
Polarization
–02
= Surface
Mount
–SH
= Single Row
Horizontal
(8,76)
.345
(5,08)
.200
(7,04)
.277
–D
= Double Row
Vertical
(5,46)
.215
02
–02
(9,58)
.377
(6,35)
.250
01 02
(2,54)
.100
(2,54)
.100
–DH
= Double Row
Horizontal
25
(3,05)
.120
–S
No. of positions x (2,54) .100 + (1,52) .060
(8,76)
.345
(5,46)
.215
(2,54) .100
(1,02)
.040
(5,46)
.215
Note:
-DH row option should be
placed on edge of board
when mating to IPD1 and
MMSD Series.
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(2,54)
.100
–02
(2,16)
.085
(3,05)
.120
(8,13)
.320
–SH
–01
(7,62)
.300
(0,64)
.025 SQ
(11,23)
.442
(5,49)
.216
–RA
(1,52)
.060
–DH
WWW.SAMTEC.COM
