150 MHz, 200 MS/s, 12-Bit Digitizer

NI PXI-5124

• 2 channels simultaneously sampled

at 12-bit resolution

• 200 MS/s real-time and 4.0 GS/s

random interleaved sampling

• 150 MHz bandwidth

• 200 mV to 20 V input range

• >75 dBc SFDR

• 8, 32, 256, or 512 MB of memory

per channel

• Edge, window, hysteresis, video,

and digital triggering with

50 ps timestamping

Operating Systems

• Windows 2000/NT/XP

Recommended Software

• LabVIEW

• LabWindows/CVI

• Measurement Studio

Driver Software (included)

• NI-SCOPE driver

• LabVIEW Express VIs

• SCOPE Soft Front Panel

• NI Spectral Measurements Toolkit

(with 32, 256 and 512 MB models)

Calibration

• Gain, offset, frequency response

and timing self-calibration

• 2 year external calibration cycle

Overview

The National Instruments PXI-5124 high-resolution digitizer

features two 200 MS/s simultaneously sampled inputs channels with

12-bit resolution, 150 MHz bandwidth, and up to 512 MB of

memory per channel in a compact 3U PXI module. The NI PXI-5124

uses the high-speed PCI bus and the scatter-gather bus mastering of

the NI MITE ASIC to move data to the computer at speeds up to 100

times faster than traditional instrument interfaces, thereby

dramatically decreasing overall test time. With the Synchronization

and Memory Core (SMC) architecture of the PXI-5124, you can

create mixed-signal systems using signal generators and digital

waveform generator/analyzers or build a high-channel-count

digitizer with subnanosecond synchronization between channels.

Triggering, Clocking, and Synchronization

• Edge, window, hysteresis, video, digital, triggering with

50 ps timestamping

• Pre and posttrigger acquisition in single and multiple-record mode

• Internal 200 MHz clock or external clock from 50 to 210 MHz

• Phase lock to PXI 10 MHz reference or external reference from

1 to 20 MHz

Software

• IVI-compliant NI-SCOPE driver for

LabVIEW, LabWindows/CVI, and

Microsoft C++ and Visual Basic with

more than 50 built-in measurements

• SCOPE Soft Front Panel

for interactive control

• Spectral Measurements Toolkit

for sophisticated frequency-domain

measurements in communications,

signal intelligence, and

avionics applications

Dual 200 MS/s, 12-Bit Input Channels

for Time and Frequency Analysis

• 150 MHz input bandwidth with anti-alias and noise filters

• >75 dBc spurious free dynamic range (SFDR)

• 4.0 GS/s equivalent time sampling for repetitive signals

• Independent channel selectable 200 mV

to 20 V

input ranges

• Independent channel selectable 50

Ω

or 1 MΩ input impedance

• 2-year calibration cycle and 0 to 55 ˚C operating temperature

Applications

Communications

xDSL

Wireless communications

Baseband I & Q

Consumer Electronics

DVD, DVD-R, and PVR

Set top box

Gaming console

Biomedical and Scientific Research

Ultrasonic medical imaging

Mass spectrometry

Particle physics

Aerospace/Defense

Emulation of IC communications

Consumer Electronics

RADAR, SONAR, and LIDAR

Satellite

Signal intelligence

Ordering Information

Deep Onboard Memory

• 8, 32, 256, or 512 MB of memory per channel

• Capture more than 1 million triggered waveforms with multiple

record hardware rearm

• Stream data continuously from onboard memory to host memory

or disk

NI PXI-5124 ..............................................................778757-0M

Includes NI-SCOPE driver and SCOPE Soft Front Panel. 32, 256, and 512 MB

models include NI Spectral Measurements Toolkit.

M (memory per channel): 1 (8 MB), 2 (32 MB), (256 MB), 4 (512 MB)
