BAT68...
Silicon Schottky Diodes
•
For mixer applications in the VHF / UHF range
•
For high-speed switching applications
•
Pb-free (RoHS compliant) package
BAT68
!
BAT68-04
BAT68-04W
!
BAT68-06
BAT68-06W
!
BAT68-07W
BAT68-08S
$
#
"
"
!
,
,
,
,
,
,
,
,
, !
!
ESD
(
E
lectro
s
tatic
d
ischarge) sensitive device, observe handling precaution!
Type
BAT68
BAT68-04
BAT68-04W
BAT68-06
BAT68-06W
BAT68-07W
BAT68-08S
Package
SOT23
SOT23
SOT323
SOT23
SOT323
SOT343
SOT363
Configuration
single
series
series
common anode
common anode
parallel pair
parallel triple
L
S
(nH)
1.8
1.8
1.4
1.8
1.4
1.6
1.4
Marking
83s
84s
84s
86s
86s
87s
83s
1
2011-06-15
BAT68...
Maximum Ratings
at
T
A
= 25°C, unless otherwise specified
Parameter
Diode reverse voltage
Forward current
Total power dissipation
BAT68,
T
S
≤
77°C
BAT68-04, BAT68-06,
T
S
≤
61°C
BAT68-04W/-06W/-08S,
T
S
≤
92°C
BAT68-07W,
T
S
≤
89°C
Junction temperature
Storage temperature
Thermal Resistance
Parameter
Junction - soldering point
1)
BAT68
BAT68-04, BAT68-06
BAT68-04W-BAT68-06W, BAT68-08S
BAT68-07W
Electrical Characteristics
at
T
A
= 25°C, unless otherwise specified
Parameter
DC Characteristics
Breakdown voltage
I
(BR)
= 10 µA
Reverse current
V
R
= 1 V
V
R
= 1 V,
T
A
= 60 °C
Forward voltage
I
F
= 1 mA
I
F
= 10 mA
1
For
Symbol
V
R
I
F
P
tot
Value
8
130
150
150
150
150
Unit
V
mA
mW
T
j
T
stg
Symbol
R
thJS
150
-55 ... 150
°C
Value
≤
490
≤
590
≤
390
≤
410
Unit
K/W
Symbol
min.
V
(BR)
I
R
-
-
V
F
-
340
8
Values
typ.
-
max.
-
Unit
V
µA
-
-
318
390
0.1
1.2
mV
340
500
calculation of
R
thJA
please refer to Application Note Thermal Resistance
2
2011-06-15
BAT68...
Electrical Characteristics
at
T
A
= 25°C, unless otherwise specified
Parameter
AC Characteristics
Diode capacitance
V
R
= 0 ,
f
= 1 MHz
Differential forward resistance
I
F
= 5 mA,
f
= 10 kHz
R
F
-
-
10
Ω
C
T
-
-
1
pF
Symbol
min.
Values
typ.
max.
Unit
3
2011-06-15
BAT68...
Diode capacitance
C
T
=
ƒ
(V
R
)
f
= 1MHz
BAT 68...
EHD07103
Differential forward resistance
r
f
=
ƒ
(I
F
)
f
= 10kHz
C
T
1.0
pF
10
3
r
f
Ω
BAT 68...
EHD07104
10
2
0.5
10
1
0
0
1
2
3
V
V
R
4
10
0
10
-1
10
0
10
1
mA
10
2
Ι
F
Reverse current
I
R
=
ƒ
(V
R
)
T
A
= Parameter
BAT 68...
EHD07102
Forward current
I
F
=
ƒ
(V
F
)
T
A
= Parameter
10
2
mA
BAT 68...
EHD07101
Ι
R
10
2
µ
A
10
1
Ι
F
T
A
= 150 C
10
1
T
A
= -40
25
85
150
C
C
C
C
10
0
85 C
10
0
10
-1
10
-2
25 C
10
-1
10
-3
0
1
2
3
V
V
R
4
10
-2
0.0
0.1
0.2
0.3
0.4
0.5 V 0.6
V
F
4
2011-06-15
BAT68...
Forward current
I
F
=
ƒ
(T
S
)
BAT68
140
mA
Forward current
I
F
=
ƒ
(T
S
)
BAT68-04, BAT68-06
140
mA
100
100
I
F
80
I
F
80
60
60
40
40
20
20
0
0
90 105 120
°C
0
0
15
30
45
60
75
150
15
30
45
60
75
90 105 120
°C
150
T
S
T
S
Forward current
I
F
=
ƒ
(T
S
)
BAT68-04W, BAT68-06W, BAT68-08S
140
mA
Forward current
I
F
=
ƒ
(T
S
)
BAT68-07W
140
mA
100
100
I
F
80
I
F
80
60
60
40
40
20
20
0
0
90 105 120
°C
0
0
15
30
45
60
75
150
15
30
45
60
75
90 105 120
°C
150
T
S
T
S
5
2011-06-15
