BAW101...
Silicon Switching Diode
•
Electrically insulated high-voltage
medium-speed diodes
•
Pb-free (RoHS compliant) package
1)
•
Qualified according AEC Q101
BAW101
"
!
,
,
Type
BAW101
Package
SOT143
Configuration
parallel
Marking
JPs
Maximum Ratings
at
T
A
= 25°C, unless otherwise specified
Parameter
Diode reverse voltage
Peak reverse voltage
Forward current
Peak forward current
Peak forward current
Surge forward current,
t
= 1 µs
Non-repetitive peak surge forward current
Total power dissipation
T
S
≤
35°C
Junction temperature
Storage temperature
1
Pb-containing
Symbol
V
R
V
RM
I
F
I
FM
I
FM
I
FS
I
FSM
P
tot
T
j
T
stg
Value
300
300
250
500
500
4.5
-
350
150
-65 ... 150
Unit
V
mA
mA
A
mW
°C
package may be available upon special request
1
2007-04-20
BAW101...
Thermal Resistance
Parameter
Junction - soldering point
1)
BAW101
Symbol
R
thJS
Value
≤
330
Unit
K/W
Electrical Characteristics
at
T
A
= 25°C, unless otherwise specified
Symbol
Values
Unit
Parameter
min.
typ. max.
DC Characteristics
300
-
-
V
Breakdown voltage
V
(BR)
I
(BR)
= 100 µA
Reverse current
V
R
= 250 V
V
R
= 250 V,
T
A
= 150 °C
Forward voltage
I
F
= 100 mA
AC Characteristics
Diode capacitance
V
R
= 0 V,
f
= 1 MHz
Reverse recovery time
I
F
= 10 mA,
I
R
= 10 mA, measured at
I
R
= 1mA,
R
L
= 100
Ω
Test circuit for reverse recovery time
D.U.T.
I
R
-
-
V
F
-
-
-
-
0.15
50
1.3
µA
V
C
T
t
rr
-
-
6
1
-
-
pF
µs
Pulse generator:
t
p
= 10µs,
D
= 0.05,
t
r
= 0.6ns,
R
i
= 50Ω
Oscillograph
Ι
F
Oscillograph:
R
= 50Ω,
t
r
= 0.35ns,
C
≤
1pF
EHN00019
1
For
calculation of
R
thJA
please refer to Application Note Thermal Resistance
2
2007-04-20
