GS8662D38BD-550I datasheet, PDF

Datasheet> All Categories > storage> storage> GS8662D38BD-550I

GS8662D38BD-550I: DescriptionQDR SRAM, 2MX36, 0.45ns, CMOS, PBGA165, 13 X 15 MM, 1 MM PITCH, FPBGA-165; Categorystorage storage; File Size445KB，33 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/

Download Datasheet Parametric View All

GS8662D38BD-550I Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GS8662D38BD-550I	-	-	View	Buy Now

GS8662D38BD-550I Overview

QDR SRAM, 2MX36, 0.45ns, CMOS, PBGA165, 13 X 15 MM, 1 MM PITCH, FPBGA-165

GS8662D38BD-550I Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	GSI Technology
Parts packaging code	BGA
package instruction	LBGA,
Contacts	165
Reach Compliance Code	compliant
ECCN code	3A991.B.2.B
Factory Lead Time	8 weeks
Maximum access time	0.45 ns
Other features	PIPELINED ARCHITECTURE
JESD-30 code	R-PBGA-B165
JESD-609 code	e0
length	15 mm
memory density	75497472 bit
Memory IC Type	QDR SRAM
memory width	36
Number of functions	1
Number of terminals	165
word count	2097152 words
character code	2000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	2MX36
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	1.4 mm
Maximum supply voltage (Vsup)	1.9 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	13 mm

Preview

Download Datasheet

View All

GS8662D20/38BD-550/500/450/400/350

GS8662D06/11BD-500/450/400/350

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.5 Clock Latency

• Simultaneous Read and Write SigmaQuad™ Interface

• JEDEC-standard pinout and package

• Dual Double Data Rate interface

• Byte Write controls sampled at data-in time

• Burst of 4 Read and Write

• On-Die Termination (ODT) on Data (D), Byte Write (BW),

and Clock (K, K) intputs

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid Pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 13 mm x 15 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

72Mb SigmaQuad-II+

Burst of 4 SRAM

550 MHz–350 MHz

1.8 V V

1.8 V or 1.5 V I/O

SRAMs. The GS8662D06/11/20/38BD SigmaQuad SRAMs

are just one element in a family of low power, low voltage

HSTL I/O SRAMs designed to operate at the speeds needed to

implement economical high performance networking systems.

Clocking and Addressing Schemes

The GS8662D06/11/20/38BD SigmaQuad-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Each internal read and write operation in a SigmaQuad-II+ B4

RAM is four times wider than the device I/O bus. An input

data bus de-multiplexer is used to accumulate incoming data

before it is simultaneously written to the memory array. An

output data multiplexer is used to capture the data produced

from a single memory array read and then route it to the

appropriate output drivers as needed. Therefore the address

field of a SigmaQuad-II+ B4 RAM is always two address pins

less than the advertised index depth (e.g., the 8M x 8 has a 2M

addressable index).

SigmaQuad-II™ Family Overview

The GS8662D06/11/20/38BD are built in compliance with

the SigmaQuad-II+ SRAM pinout standard for Separate I/O

synchronous SRAMs. They are 75,497,472-bit (72Mb)

Parameter Synopsis (x18/x36)

-550

tKHKH

tKHQV

1.81 ns

0.29ns

-500

2.0 ns

0.33 ns

-450

2.2 ns

0.37 ns

-400

2.5 ns

0.45 ns

-350

2.86 ns

0.45 ns

Parameter Synopsis (x8/x9)

-500

tKHKH

tKHQV

2.0 ns

0.33 ns

-450

2.2 ns

0.37ns

-400

2.5 ns

0.45 ns

-350

2.86 ns

0.45 ns

Rev: 1.02b 11/2011

1/33

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
