D- SUB C on ne c t o r s
D-SUB Standard
Interface adapter – Gender Changer – Configuration of contacts 1:1
Description
Variation plug to plug and socket to socket
Stamped contacts
4-40 UNC threaded lock
Quality class 3 (other quality classes on request)
Shell: Steel tin plated
RoHS compliant – CSA listed, File No.: LR 115000-1 – UL listed, File No.: E202784
Product drawing
Variation socket to socket
No. of pos.
09
15
25
37
Variation plug to plug
A
-0.76
31.19
39.52
53.42
69.70
B
-0.25
16.46
24.79
38.50
54.96
C
25.00
33.30
47.04
63.50
+ 0.12
+ 0.15
- 0.10
± 0.13
± 0.13
No. of pos.
09
15
25
37
A
-0.76
31.19
39.52
53.42
69.70
B
+0.25
16.79
25.12
38.84
55.30
C
25.00
33.30
47.04
63.50
+ 0.12
+ 0.15
- 0.10
± 0.13
± 0.13
D
-0.30
16.46
24.79
38.50
54.96
Order data
Socket connector – socket connector
No. of pos.
09
15
25
37
Plug connector – Plug connector
Part Number
320X 12519
320X 12539
320X 10559
320X 12559
X
X
X
X
Mounting style 4-40 UNC
Threaded lock
Threaded lock
Threaded lock
Threaded lock
No. of pos.
09
15
25
37
Mounting style 4-40 UNC
Threaded lock
Threaded lock
Threaded lock
Threaded lock
Part Number
320X 12509
320X 12529
320X 10549
320X 12549
X
X
X
X
1| 57
