TX3-801HT
SMD TCXO
HCMOS
Features
Applications: mobile communications, instrumentation,
microwave
Frequency range up to 50 MHz
Tight frequency stability vs. temperature
Low phase noise
Parameter
Frequency range
Standard frequencies
Frequency stability:
vs. temperature
vs. supply & load change
vs. aging
Frequency tolerance ex. factory
Supply voltage
Supply current
Output signal
Output load
Frequency adjustment
Phase noise @ 13.0 MHz carrier frequency
Operating temperature range
Storage temperature range
Packaging units
Customer specifications on request
Specification
TX3-801HTL
TX3-801HTM
TX3-801HTS
10 ~ 30 MHz
10 ~ 50 MHz
10.00, 13.00, 16.384, 19.20, 19.44, 20.00, 20.48 & 27.00 MHz
1.0
~
2.5 ppm
0.2
ppm
5
%
st
1.0
ppm
1 year
0.5
ppm
@ +25 °C
3.0 V
5
%
3.3 V
5
%
5.0 V
5
%
4 ~ 15 mA
HCMOS
15 pF
> ± 3 ppm
by internal trimmer
-140 dBc/Hz
@ 1 kHz
-30 ~ +75 °C
commercial application
-40 ~ +85 °C
industrial application
-55 ~ +125 °C
tape & reel
500 or 1’000 pieces
Pin function
#1
#2
#3
#4
not connected
GND
Output
Vdc
Example for solder pattern
Do not design any conductive path between the pattern
Example for IR reflow soldering temperature
2002/95/EC RoHS compliant
QuartzCom AG
sales@quartzcom.com
www.quartzcom.com
QuartzCom Asia
sales-asia@quartzcom.com
QuartzCom USA
sales-usa@quartzcom.com
30 Apr. 10
