F-210-1
SEAF–20–05.0–S–10–2–A–K–TR
(1,27mm) .050"
SEAF–30–05.0–S–08–2–A–K–TR
SEAF SERIES
SEAF–30–06.5–S–08–2–A–K–TR
HIGH SPEED/HIGH DENSITY OPEN PIN FIELD
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?SEAF
Insulator Material:
Black LCP
Contact Material:
Copper Alloy
Solder Charge:
95.5% Sn, 3.8% Ag, 0.7% Cu
(Tin/Lead also available.
Call Samtec.)
Operating Temp Range:
-55°C to +125°C
Plating:
Au or Sn over 50µ" (1,27µm) Ni
Contact Resistance:
5.5 mΩ
Working Voltage:
240 VAC
RoHS Compliant:
Yes
Lead-Free Solderable:
Yes
Mates with:
SEAM, SADL,
SEAMP,
SEAC
(Requires –LP)
(1,50mm)
.059"
NOMINAL
WIPE
Up to
500 Pins
5, 8 and 10 row footprint
compatible with SamArray
®
.
Samples recommended.
Solder
charges
TM
EXTENDED LIFE PRODUCT
10 Year Mixed Flowing Gas (MFG)
Call Samtec for maximum cycles mated with SEAM
CURRENT RATING
Low Insertion/
Extraction Forces
®
ry
dust ds
In
r
anda
St
ls
toco d
Pro orte
Supp
PISMO 2
VITA 47
VITA 57
fina
l
i
nch.com
7mm Stack Height
Rated @ 3dB Insertion Loss
Single-Ended Signaling
9.5 GHz / 19 Gbps
Differential Pair Signaling
10.5 GHz / 21 Gbps
Performance data for other stack heights and
complete test data available at www.samtec.com?SEAF
or contact sig@samtec.com
AMBIENT
SEAM/SEAF
TEMP
2.3A
20°C
2A
40°C
1.75A
60°C
1.14A
95°C
30 ADJACENT
POSITIONS POWERED
SEAF
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
B
(5,61)
.221
(8,20)
.323
(10,69)
.421
(13,23)
.521
08
PLATING
OPTION
NO. OF
ROWS
2
A
OPTION
K
TR
–L
= 10µ"
(0,25µm)
Gold on
contact area,
Matte Tin on
solder tail
– 04
=Four
Rows
Downloa
om/appnote
www.samtec.c mtec.com
@ sa
Contact SIG n protocols
o
for questions
nel
Fibre Chan
Rapid I/O
®
s
PCI Expres
SATA
Infiniband
at
d app notes
–10, –15, – 20,
– 30, –40, –50
(–10 only available in 04 row)
(–15 only available in 10 row)
LEAD
STYLE
–05.0
–06.0
–06.5
–08.0
–2
= Lead-Free
Solder Charge
– LP
=Latch Post
(–LP required
for SEAC mate only)
– 05
=Five
Rows
A
(5,05)
.199
(6,05)
.238
(6,55)
.258
(8,05)
.317
NO. OF
ROWS
–04.0
–05, –06
–08
–10
(1,27) .050
–S
= 30µ"
(0,76µm)
Gold on
contact area,
Matte Tin on
solder tail
(1,27)
.050
– 06
=Six
Rows
APPLICATION SPECIFIC
–07.5 lead style for 30x4 available.
Call Samtec.
– 08
=Eight
Rows
ALSO AVAILABLE
Rugged solder crimp option.
Call Samtec.
MATED HEIGHTS*
SEAF LEAD STYLE
–05.0 –06.0 –06.5 –08.0
7mm
8mm
8mm
9mm
8.5mm 10mm
9.5mm 11mm
– 10
=Ten
Rows
DIFFERENTIAL
(1,27) .050
(1,27)
.050
PAIR
ARRAY COUNT
125
50x10
100
50x8
100
40x10
PAIR
ARRAY COUNT
80
40x8
60
40x6
75
30x10
60
30x8
45
30x6
20x10
50
20x8
40
20x5
25
B
No. of positions x
01
(1,27) .050 + (5,82) .229
(15,49)
.610
(1,27)
.050
(1,78)
.070
A
(1,12) .044 DIA
No. of positions x
(1,27) .050 + (3,58) .141
SEAM
LEAD
STYLE
–02.0
–03.0
–03.5
–06.5
–07.0
–09.0
–11.0
8.5mm 9.5mm 10mm 11.5mm
11.5mm 12.5mm 13mm 14.5mm
12mm
14mm
13mm 13.5mm 15mm
15mm 15.5mm 17mm
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(0,20)
.008
–LP
16mm 17mm 17.5mm 19mm
*Processing conditions will affect
mated height.
WWW.SAMTEC.COM
