HZS-LL Series
P
D
: 250 mW
FEATURES :
* High reliability
* Low leakage current, low dynamic resistance
* Pb / RoHS Free
ZENER DIODES
DO - 34 Glass
0.078 (2.0 )max.
1.00 (25.4)
min.
Cathode
Mark
0.118 (3.0)
max.
0.017 (0.43)max.
MECHANICAL DATA
Case:
DO-34 Glass Case
Weight:
approx. 0.093g
1.00 (25.4)
min.
Dimensions in inches and ( millimeters )
MAXIMUM RATINGS
Rating at 25
°
C ambient temperature unless otherwise specified
Parameter
Forward Rectifier Current
Power Dissipation
Junction Temperature
Storage Temperature Range
Symbol
I
F
P
D
Tj
T
stg
Value
50
250
175
- 55 to + 175
Unit
mA
mW
°C
°C
ELECTRICAL CHARACTERISTICS
Rating at 25
°
C ambient temperature unless otherwise specified
Test
Maximum
Zener Voltage
Current
Reverse Current
Grade
Type
I
ZT
I
R
@ V
R
Vz (V)
min.
max.
(mA)
(nA)
(V)
A
1.6
2.0
B
1.9
2.3
C
2.2
2.6
A
2.5
2.9
HZS3LL
B
2.8
3.2
C
3.1
3.5
A
3.4
3.8
HZS4LL
B
3.7
4.1
C
4.0
4.4
A
4.3
4.7
HZS5LL
B
4.6
5.0
C
4.9
5.3
*
Δ
V
Z1
= V
Z
(I
Z
= 0.5 mA) - V
Z1
(I
Z
= 0.05 mA)
Δ
V
Z1
= V
Z1
(I
Z
= 0.5 mA) - V
Z2
(I
Z
= 0.05 mA)
HZS2LL
Note:
When place an order HZS series, named HZS2ALL, HZS2BLL
⋅⋅⋅⋅⋅⋅⋅
HZS5CLL
-LL
Maximum Zener
Impredance
ZZT @ IZT
(Ω)
(mA)
Typical Zener
Impredance
Z
ZK
@ I
ZK
(KΩ)
(mA)
ΔVz
(V)
ΔV
Z1
*
max
ΔV
Z2
*
max
0.5
100
0.5
350
0.5
1.2
50
0.5
0.6
0.5
100
1.0
360
0.5
1.2
50
0.5
0.6
0.5
100
2.0
370
0.5
1.5
50
0.5
0.6
0.5
100
3.0
380
0.5
1.5
50
0.5
0.6
Page 1 of 1
Rev. 03 : December 3, 2008
