Amphenol
Miniature Box Interconnects
G825M
Materials
Housing
Contacts
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– 1A
– 250 VAC/rms 60Hz
2mm DIL Pin Headers SMT Mount
Durability
Gold Flash
15µ” Gold
30µ” Gold
– 75 cycles
– 150 cycles
– 250 cycles
– Page G-12/13
– Page G-14
– Page G-11
Complete modular connector system
Electrical
Current
Voltage
Mating Half
2mm PCB Rec
2mm Wire Rec
2mm Jumper
Part Number System:
G825M XX X X X X
2mm Pin Headers
SMT Mount
NUMBER OF POSITIONS
Dual row: 04 to 50
CONTACT FINISH
1: Gold flash
2: 10µ” Gold
3: 30µ” Gold
No. of
Positions
4
6
8
10
12
14
16
18
20
22
24
26
Dimensions
B
2
4
6
8
10
12
14
16
18
20
22
24
No. of
Positions
28
30
32
34
36
38
40
42
44
46
48
50
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
MOUNTING TYPE
1: Standard
2: With locating peg
HEIGHT OF INSULATOR
0: 1.4mm
1: 2.3mm
Dimensions
B
26
28
30
32
34
36
38
40
42
44
46
48
A
4
6
8
10
12
14
16
18
20
22
24
26
C
2
4
6
8
10
12
14
16
18
20
22
A
28
30
32
34
36
38
40
42
44
46
48
50
C
24
26
28
30
32
34
36
38
40
42
44
46
Dimensions in mm
AMTA Pin&Socket Catalogue
G890
Materials
Mini Jumpers 2mm Pitch
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– Full Gold Flash
– 1A
– 250 VAC/rms 60Hz
– 75 cycles
– G-9/10/11
Suffix may be added
to Part Number.
This Suffix is for
Internal use mainly.
Additional Suffix ‘EU’
or ‘LF’ may be
added for RoHS
compliant product.
Housing
Contacts
Contact Finish
Electrical
Current
Voltage
Durability
Full Gold Flash
Mating Half
Pin Header 2mm
Part Number:
G89012020020
G89012030020
G89012021020
G89012031020
G89012022020
G89012032020
AMTA
Type
Open
Closed
Open
Closed
Colour
Black
Blue
Dimensions in mm
Open
Closed
Yellow
PNS-890 Rev. D/OTHER-G89012030-29 Rev. A/OTHER-G89012020 Rev. C
G-11
