GS8662D11BGD-333I datasheet, PDF

Datasheet> All Categories > storage> storage> GS8662D11BGD-333I

GS8662D11BGD-333I: DescriptionStandard SRAM, 8MX9, 0.45ns, CMOS, PBGA165, 15 X 13 MM, 1 MM PITCH, ROHS COMPLIANT, FPBGA-165; Categorystorage storage; File Size690KB，34 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric View All

GS8662D11BGD-333I Overview

Standard SRAM, 8MX9, 0.45ns, CMOS, PBGA165, 15 X 13 MM, 1 MM PITCH, ROHS COMPLIANT, FPBGA-165

GS8662D11BGD-333I Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	GSI Technology
Parts packaging code	BGA
package instruction	15 X 13 MM, 1 MM PITCH, ROHS COMPLIANT, FPBGA-165
Contacts	165
Reach Compliance Code	compliant
ECCN code	3A991.B.2.B
Maximum access time	0.45 ns
Other features	PIPELINED ARCHITECTURE
JESD-30 code	R-PBGA-B165
JESD-609 code	e1
length	15 mm
memory density	75497472 bit
Memory IC Type	STANDARD SRAM
memory width	9
Humidity sensitivity level	3
Number of functions	1
Number of terminals	165
word count	8388608 words
character code	8000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	8MX9
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.4 mm
Maximum supply voltage (Vsup)	1.9 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	13 mm

Preview

Download Datasheet

View All

Preliminary

GS8662D06/20/38BD-550/500/450/400/350

GS8662D11BD-500/450/400/350

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• 2.5 Clock Latency

• Simultaneous Read and Write SigmaQuad™ Interface

• JEDEC-standard pinout and package

• Dual Double Data Rate interface

• Byte Write controls sampled at data-in time

• Burst of 4 Read and Write

• On-Die Termination (ODT) on Data (D), Byte Write (BW),

and Clock (K, K) intputs

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• Data Valid Pin (QVLD) Support

• IEEE 1149.1 JTAG-compliant Boundary Scan

• 165-bump, 13 mm x 15 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

72Mb SigmaQuad-II+

Burst of 4 SRAM

550 MHz–350 MHz

1.8 V V

1.8 V or 1.5 V I/O

SRAMs. The GS8662D06/11/20/38BD SigmaQuad SRAMs

are just one element in a family of low power, low voltage

HSTL I/O SRAMs designed to operate at the speeds needed to

implement economical high performance networking systems.

Clocking and Addressing Schemes

The GS8662D06/11/20/38BD SigmaQuad-II+ SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer.

Because Separate I/O SigmaQuad-II+ B4 RAMs always

transfer data in four packets, A0 and A1 are internally set to 0

for the first read or write transfer, and automatically

incremented by 1 for the next transfers. Because the LSBs are

tied off internally, the address field of a SigmaQuad-II+ B4

RAM is always two address pins less than the advertised index

depth (e.g., the 4M x 18 has a 1M addressable index).

SigmaQuad-II™ Family Overview

The GS8662D06/11/20/38BD are built in compliance with

the SigmaQuad-II+ SRAM pinout standard for Separate I/O

synchronous SRAMs. They are 75,497,472-bit (72Mb)

Parameter Synopsis (x8/x18/x36)

-550

tKHKH

tKHQV

1.81 ns

0.29ns

-500

2.0 ns

0.33 ns

-450

2.2 ns

0.37 ns

-400

2.5 ns

0.45 ns

-350

2.86 ns

0.45 ns

Parameter Synopsis (x9)

-500

tKHKH

tKHQV

2.0 ns

0.33 ns

-450

2.2 ns

0.37ns

-400

2.5 ns

0.45 ns

-350

2.86 ns

0.45 ns

Rev: 1.01 11/2010

1/34

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
