SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 5090, REV. A
Ultrafast Recovery Rectifier
•
Hermetic, non-cavity glass package
•
Metallurgically bonded
o
o
•
Operating and Storage Temperature: -65 C to +175
SS6620,U,US thru SS6625,U,US
MAX. RATINGS / ELECTRICAL CHARACTERISTICS
Rating
WORKING PEAK REVERSE VOLTAGE
1N6620, U, US
1N6621, U ,US
1N6622, U, US
1N6623, U, US
1N6624 ,U, US
1N6625, U, US
AVERAGE RECTIFIED FORWARD CURRENT
1N6620, U, US thru 1N6622, U, US
1N6623, U, US thru 1N6625, U, US
PEAK FORWARD SURGE CURRENT
1N6620, U, US thru 1N6624,U, US
1N6625, U, US
MAXIMUM REVERSE CURRENT
1N6620, U, US thru 1N6624,U, US
1N6625, U, US
MAXIMUM REVERSE CURRENT
1N6620, U, US thru 1N6624,U, US
1N6625, U, US
MAX. PEAK FORWARD VOLTAGE (PULSED)
1N6620, U, US thru 1N6622,U, US
1N6623,U, US & 1N6624,U, US
1N6625, U, US
PEAK RECOVERY CURRENT
1N6620, U, US thru 1N6622,U, US
1N6623,U, US & 1N6624,U, US
1N6625, U, US
MAXIMUM REVERSE RECOVERY TIME
1N6620, U, US thru 1N6622,U, US
1N6623,U, US & 1N6624,U, US
1N6625, U, US
FORWARD RECOVERY VOLTAGE
1N6620, U, US thru 1N6622,U, US
1N6623,U, US & 1N6624,U, US
1N6625, U, US
THERMAL RESISTANCE (Axial)
1N6620 thru 1N6625
THERMAL RESISTANCE (MELF)
1N6620U,US thru 1N6625U,US
o
All ratings are at T
A
= 25 C unless otherwise
specified.
Symbol
Condition
Max
200
400
600
800
900
1000
1.2
1.0
Units
V
RWM
Volts
I
o
Amps
I
FSM
T
p
=8.3ms
20
15
0.5
1.0
150
200
1.60
1.80
1.95
3.5
4.2
5.0
30
50
60
12
18
30
38
A(pk)
I
R
@ V
RWM
T
j
= 25
o
C
T
j
= 150
o
C
μAmps
μAmps
I
R
@ V
RWM
V
FM
I
F
=2.0A
I
F
=1.5μA
I
F
=1.5μA
I
F
=2A,
100A/μ
Volts
I
RM
A(pk)
T
rr
I
F
=0.5A
I
RM
=1.0A
ns
V
FRM
I
F
=0.5A
t
r
=12ns
L=.375
L=0
Volts
Rθ
JL
Rθ
JC
o
C/W
C/W
o
20
•
221 West Industry Court
Deer Park, NY 11729-4681 Phone (631) 586 7600 Fax (631) 242 9798
•
•
World Wide Web Site - http://www.sensitron.com
•
E-Mail Addre1N - sales@sensitron.com
•
