L6006L8TP56 Overview

TRIAC,

L6006L8TP56 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerLittelfuse
package instruction,
Reach Compliance Codeunknown
JESD-609 codee3
Peak Reflow Temperature (Celsius)260
Terminal surfaceMatte Tin (Sn)
Maximum time at peak reflow temperature40
Thyristors
6 Amp Sensitive, Standard & Alternistor (High Commutation) Triacs
Lxx06xx & Qxx06xx & Qxx06xHx Series
Description
RoHS
This 6 Amp bidirectional solid state switch series is
designed for AC switching and phase control applications
such as motor speed and temperature modulation controls,
lighting controls, and static switching relays.
Sensitive
type components guarantee gate control in
Quadrants I & IV as needed for digital control circuitry.
Standard
type components normally operate in Quadrants
I & III triggered from AC line.
Alternistor
type components only operate in quadrants
I, II, & III and are used in circuits requiring high dv/dt
capability.
Features & Benefits
Agency Approval
Agency
Agency File Number
E71693*
* - L Package Only
• RoHS compliant
• Glass – passivated
junctions
• Voltage capability up
to 1000 V
• Surge capability up
to 85 A
• The L-package has
an isolation rating of
2500V
RMS
• Solid-state switching
eliminates arcing or
contact bounce that
create voltage transients
Applications
• No contacts to wear out
from reaction of switching
events
• Restricted (or limited) RFI
generation, depending on
activation point of
sine wave
• Only requires a short gate
activation pulse during
each half-cycle
Main Features
Symbol
I
T(RMS)
V
DRM
/V
RRM
I
GT (Q1)
Value
6
400, 600, 800 or 1000
5 to 50
Unit
A
V
mA
Schematic Symbol
Excellent for AC switching and phase control applications
such as heating, lighting, and motor speed controls.
Typical applications are AC solid-state switches, light
dimmers, power tools, home/brown goods and white
goods appliances.
Alternistor Triacs (no snubber required) are used in
applications with extremely inductive loads requiring the
highest commutation performance.
Internally constructed isolated packages are offered for
ease of heat sinking with highest isolation voltage.
MT2
MT1
G
Absolute Maximum Ratings — Sensitive Triac
(4 Quadrants)
Symbol
I
T(RMS)
I
TSM
I
2
t
di/dt
I
GTM
P
G(AV)
T
stg
T
J
RMS on-state current (full sine wave)
Non repetitive surge peak on-state current
(full cycle, T
J
initial = 25°C)
I
2
t Value for fusing
Critical rate of rise of on-state current
I
G
= 50mA with 0.1µs rise time
Peak gate trigger current
Average gate power dissipation
Storage temperature range
Operating junction temperature range
f = 120 Hz
t
p
=20μs
Parameter
Lxx06Ly/Lxx06Vy/Lxx06Dy
Lxx06Ry/Lxx06Ny
f = 50 Hz
f = 60 Hz
t
p
= 8.3 ms
T
J
= 110°C
T
J
= 110°C
T
J
= 110°C
T
C
= 80°C
T
C
= 85°C
t = 20 ms
t = 16.7 ms
Value
6
50
60
15
70
4
0.4
-40 to 150
-40 to 110
Unit
A
A
A
2
s
A/μs
A
W
°C
°C
Note: xx = voltage/10, y = sensitivity
© 2018 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 11/29/18
