SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 5191, Rev. -
SHDC625052
SHDC625052P
SHDC625052N
SHDC625052D
HERMETIC SILICON CARBIDE RECTIFIER
DESCRIPTION:
A 1200-VOLT, 10 AMP POWER SILICON CARBIDE RECTIFIER IN A CERAMIC
HERMETIC TO-254 PACKAGE (GLASS SEALS NOT AVAILABLE FOR THIS VOLTAGE)
FEATURES:
•
NO RECOVERY TIME OR REVERSE RECOVERY LOSSES
•
NO TEMPERATURE INFLUENCE ON SWITCHING BEHAVIOR
•
High Frequency Option
- Non-magnetic Glidcop leads are available for improved performance at
high frequency; use part number prefix SHDG
MAXIMUM RATINGS
RATING
PEAK INVERSE VOLTAGE
MAXIMUM DC OUTPUT CURRENT (With T
C
= 65
O
C, for part numbers
with P and N suffixes)
MAXIMUM DC OUTPUT CURRENT (With T
C
= 65
O
C, for part number
with D suffix or without suffix)
MAXIMUM NON-REPETITIVE FORWARD SURGE CURRENT
(t = 8.3ms, Sine) per leg, T
C
= 25
O
C
MAXIMUM NON-REPETITIVE FORWARD SURGE CURRENT
(t = 10μs, pulse) per leg, T
C
= 25
O
C
MAXIMUM POWER DISSIPATION, T
C
= 25
O
C
MAXIMUM THERMAL RESISTANCE, Junction to Case (PER DUAL
PACKAGE For Common Cathode/Anode Configurations)
MAXIMUM OPERATING AND STORAGE TEMPERATURE RANGE*
ALL RATINGS ARE @ T
C
= 25
°C
UNLESS OTHERWISE SPECIFIED.
SYMBOL
PIV
I
O
I
O
I
FRM
I
FSM
P
d
R
θJC
Top, Tstg
MAX.
1200
10
5
30
100
30
1.50
-55 to
+200
UNITS
Volts
Amps
Amps
Amps
Amps
W
°C/W
°C
*
Note: SiC semiconductors will handle at or above this operating and storage temperature. However, extended
operational use of the packaged device above 175C may reduce its future performance. All qualification testing and
screening per MIL-PRF-19500 will only be performed to 175C.
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
MAXIMUM FORWARD VOLTAGE DROP (I
f
= 5 A PER LEG) V
f
T
J
=25
°C
T
J
=150
°C
MAXIMUM REVERSE CURRENT (1200V PIV PER LEG) I
r
T
J
= 25
°C
T
J
= 150
°C
TOTAL CAPACITIVE CHARGE (V
R
= 1200V, I
F
= 5A, di/dt = 500A/μs) Q
C
JUNCTION CAPACITANCE (V
r
= 5V) per leg
C
T
TYP
1.65
2.55
0.05
0.10
28
450
MAX.
1.80
3.00
0.20
1.00
N/A
mA
nC
pF
Volts
UNITS
©2010 Sensitron Semiconductor
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
PHONE (631) 586-7600
•
FAX (631) 242-9798
•
www.sensitron.com
•
sales@sensitron.com
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 5191, Rev. -
PINOUT TABLE
TYPE
SINGLE RECTIFIER
DUAL RECTIFIER/COMMON CATHODE (P)
DUAL RECTIFIER/COMMON ANODE (N)
DUAL RECTIFIER/DOUBLER (D)
SHDC625052
SHDC625052P
SHDC625052N
SHDC625052D
PIN 1
CATHODE
ANODE 1
CATHODE 1
ANODE
PIN 2
ANODE
COMMON
CATHODE
COMMON
ANODE
ANODE/
CATHODE
PIN 3
ANODE
ANODE 2
CATHODE 2
CATHODE
SCHEMATIC
1
2
SINGLE
3
1
2
3
COMMON CATHODE
1
2
3
COMMON ANODE
3
2
DOUBLER
1
Application Note: Customers should be aware that at the current stage of technical development of SiC, the reverse
avalanche capabilities of the device are limited.
Customer designs will need to accommodate these limitations and avoid exposure of the device to this and other
potentially damaging conditions in their applications.
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product
characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version of the
datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment, medical
equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature assured safety or by means of users’
fail-safe precautions or other arrangement .
3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during operation of
the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual property claims or any
other problems that may result from applications of information, products or circuits described in the datasheets.
4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from use at
a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of Sensitron
Semiconductor.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will hinder
maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third party. When
exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and regulations.
