LS3
Molded
Shielded Inductors
.410" ± .020"
22 AWG/TCW
1.15"nominal
0.162" ± 0.010"
These reliable subminiature shielded inductors are especially suited for high-density applications. All feature magnetic
shielding, excellent inductance-to-size ratios, low DC resistance and high Q.
INDUCTANCES 0.1 µH to 1,000 µH
OPERATING TEMPERATURES
Temperature: 90°C.
-55°C to +105°C. Ambient
TESTING Inductanceand Q measured withQ meter HP4342A
at specified frequency. DCR measured with Milliohm meter.
SRF measured on HP4191A meter.
MARKING 5-Band color code.
PACKAGING Bulk or Tape and Reel.
INDUCTANCE TOLERANCE±10%over entire inductancerange.
SHIELDING Less than 3%coupling, units side by side at 1 kHz.
INCREMENTAL CURRENT DC current which will causereduction
of 5% in inductance.
PART
NUMBER
LS3-R10K
LS3-R12K
LS3-R15K
LS3-R18K
LS3-R22K
LS3-R27K
LS3-R33K
LS3-R39K
LS3-R47K
LS3-R65K
LS3-R68K
LS3-R82K
LS3-1R0K
LS3-1R2K
LS3-1R5K
LS3-1R8K
LS3-2R2K
LS3-2R7K
LS3-3R3K
LS3-3R9K
LS3-4R7K
LS3-5R6K
LS3-6R8K
LS3-8R2K
LS3-100K
LS3-120K
LS3-150K
LS3-180K
LS3-220K
LS3-270K
LS3-330K
LS3-390K
LS3-470K
LS3-560K
LS3-680K
LS3-820K
LS3-101K
LS3-121K
LS3-151K
LS3-181K
LS3-221K
LS3-271K
LS3-331K
LS3-391K
LS3-471K
LS3-561K
LS3-681K
LS3-821K
LS3-102K
INDUCTANCE
(µH)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Q
MINIMUM
50
51
51
50
49
47
46
44
44
43
42
40
40
44
44
44
44
44
44
44
44
44
50
50
50
55
45
45
45
45
45
50
50
40
50
50
50
55
55
55
55
55
55
60
60
60
60
57
65
TEST
FREQUENCY
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
SELF RESONANT
FREQUENCY
MINIMUM (MHz)
250
250
250
250
250
250
250
250
235
210
190
180
140
130
115
105
100
92
85
75
70
65
55
50
46
44
49
45
41
38
34
29
27
25
21
10.5
10.0
9.7
8.5
8.0
7.5
7.0
6.5
6.2
5.7
4.7
4.5
4.2
3.8
DC RESISTANCE
OHMS
MAXIMUM (Ω )
.025
.034
.037
.047
.067
.110
.130
.180
.250
.330
.450
.590
.070
.10
.12
.14
.19
.28
.35
.40
.55
.72
1.02
1.32
1.62
2.00
0.80
0.89
0.96
1.19
1.37
1.93
2.11
2.23
2.70
2.44
3.12
3.60
4.10
4.40
5.00
5.80
6.40
7.40
9.50
10.50
11.80
13.00
17.50
RATED DC
CURRENT MAX
(mA)
1790
1530
1470
1300
1100
855
780
670
565
490
420
370
1070
895
815
775
650
535
480
450
380
335
280
250
220
200
315
300
290
260
240
205
195
190
170
180
160
150
140
135
125
115
110
105
92
90
80
80
70
INCREMENTAL
CURRENT
(mA)
1790
1530
1470
1300
1100
855
780
670
565
490
420
370
1070
895
815
775
650
535
480
450
380
335
280
250
220
200
250
235
220
200
190
180
175
160
150
140
120
95
90
85
80
70
65
60
58
55
50
45
40
