2SB1457_09 Overview

Micro Motor Drive, Hammer Drive Applications Power Switching Applications Power Amplifier Applications

2SB1457
TOSHIBA Transistor Silicon PNP Epitaxial Type (Darlington)
2SB1457
Micro Motor Drive, Hammer Drive Applications
Power Switching Applications
Power Amplifier Applications
Unit: mm
High DC current gain: h
FE
= 2000 (min) (V
CE
=
−2
V, I
C
=
−1
A)
Low saturation voltage: V
CE (sat)
=
−1.5
V (max)
(I
C
=
−1
A, I
B
=
−1
mA)
Absolute Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C (DC)
I
C (Pulse)
I
B
P
C
T
j
T
stg
Rating
−100
−100
−8
−2
−3
−0.5
900
150
−55
to 150
Unit
V
V
V
A
A
A
mW
°C
°C
JEDEC
JEITA
TOSHIBA
TO-92MOD
2-5J1A
Weight: 0.36 g (typ.)
Note1: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/Derating Concept and Methods) and individual reliability data (i.e. reliability test report
and estimated failure rate, etc).
Equivalent Circuit
COLLECTOR
BASE
≈ 4 kΩ
≈ 800 Ω
EMITTER
1
2009-12-21
