Green
RS1A/B - RS1M/B
1.0A SURFACE MOUNT FAST RECOVERY RECTIFIER
Features
•
•
•
•
•
•
Glass Passivated Die Construction
Fast Recovery Time For High Efficiency
Surge Overload Rating to 30A Peak
Ideally Suited for Automated Assembly
Lead Free Finish/RoHS Compliant (Note 1)
Green Molding Compound (No Halogen and Antimony)
(Note 2)
Mechanical Data
•
•
•
•
•
•
Case: SMA/SMB
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Lead Free Plating (Matte Tin Finish). Solderable per
MIL-STD-202, Method 208
Polarity: Cathode Band or Cathode Notch
Weight: SMA - 0.064 grams (approximate)
SMB - 0.093 grams (approximate)
Top View
Bottom View
Ordering Information
(Note 3)
Part Number
RS1x-13-F
RS1xB-13-F
Notes:
Case
SMA
SMB
Packaging
5000/Tape & Reel
3000/Tape & Reel
* x = Device type, e.g. RS1D-13-F (SMA package); RS1JB-13-F (SMB package).
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes.
2. Product manufactured with Data Code 0924 (week 24, 2009) and newer are built with Green Molding Compound.
3. For packaging details, go to our website at http://www.diodes.com.
Marking Information
YWW
RS1x(B)
RS1x = Product Type Marking Code, ex: RS1G (SMA package)
RS1xB = Product Type Marking Code, ex: RS1GB (SMB package)
= Manufacturer’s Code Marking
YWW = Date Code Marking
Y = Last Digit of Year (ex: 6 for 2006)
WW = Week code (01 to 53)
RS1A/B - RS1M/B
Document number: DS15002 Rev. 13 - 2
1 of 4
www.diodes.com
September 2010
© Diodes Incorporated
RS1A/B - RS1M/B
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage (Note 4)
RMS Reverse Voltage
Average Rectified Output Current
@ T
T
= 120°C
Non-Repetitive Peak Forward Surge Current, 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
RS1
A/AB
50
35
RS1
B/BB
100
70
RS1
D/DB
200
140
RS1
G/GB
400
280
1.0
30
RS1
J/JB
600
420
RS1
K/KB
800
560
RS1
M/MB
1000
700
Unit
V
V
A
A
Thermal Characteristics
Characteristic
Typical Thermal Resistance, Junction to Terminal (Note 5)
Operating and Storage Temperature Range
Symbol
R
θ
JT
T
J,
T
STG
Value
20
-65 to +150
Unit
°C/W
°C
Electrical Characteristics
Characteristic
Forward Voltage Drop
Peak Reverse Current
at Rated DC Blocking Voltage (Note 4)
Reverse Recovery Time (Note 6)
Typical Total Capacitance (Note 7)
Notes:
@T
A
= 25°C unless otherwise specified
Symbol
@ I
F
= 1.0A
@ T
A
= 25°C
@ T
A
= 125°C
V
FM
I
RM
t
rr
C
T
150
15
RS1
A/AB
RS1
B/BB
RS1
D/DB
RS1
G/GB
1.3
5.0
200
RS1
J/JB
RS1
K/KB
RS1
M/MB
Unit
V
µA
250
500
ns
pF
4. Short duration pulse test used to minimize self-heating effect.
5. Valid provided that terminals are kept at ambient temperature.
6. Reverse recovery test conditions: I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A. See figure 5.
7. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
1.0
I
F,
INSTANTANEOUS FORWARD CURRENT (A)
1.2
I
O
, AVERAGE RECTIFIED CURRENT (A)
10
0.8
1.0
0.6
0.4
0.1
0.2
T
J
= 25
o
C
0
25
50
75
100
125
150
T
T
, TERMINAL TEMPERATURE (
°
C)
Fig. 1 Forward Current Derating Curve
175
0.01
0
0.4
0.8
1.2
1.6
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
RS1A/B - RS1M/B
Document number: DS15002 Rev. 13 - 2
2 of 4
www.diodes.com
September 2010
© Diodes Incorporated
RS1A/B - RS1M/B
I
R
, INSTANTANEOUS REVERSE CURRENT (µA)
30
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
1,000
T
J
= 125
°
C
100
20
10
10
T
J
= 25°C
1.0
0
1
10
100
NUMBER OF CYCLES AT 60Hz
Fig. 3 Forward Surge Current Derating Curve
0.1
0
20
40
60
80
100
120 140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 4 Typical Reverse Characteristics
Package Outline Dimensions
B
A
C
D
J
SMA
Dim
Min
Max
A
2.29
2.92
B
4.00
4.60
C
1.27
1.63
D
0.15
0.31
E
4.80
5.59
G
0.05
0.20
H
0.76
1.52
J
2.01
2.30
All Dimensions in mm
SMB
Dim
Min
Max
A
3.30
3.94
B
4.06
4.57
C
1.96
2.21
D
0.15
0.31
E
5.00
5.59
G
0.05
0.20
H
0.76
1.52
J
2.00
2.50
All Dimensions in mm
H
E
G
RS1A/B - RS1M/B
Document number: DS15002 Rev. 13 - 2
3 of 4
www.diodes.com
September 2010
© Diodes Incorporated
RS1A/B - RS1M/B
Suggested Pad Layout
C
X
SMA
Value (in mm)
Dimensions
Z
6.5
G
1.5
X
1.7
Y
2.5
C
4.0
Y
G
Z
SMB
Value (in mm)
Dimensions
Z
6.7
G
1.8
X
2.3
Y
2.5
C
4.3
