DATA SHEET
SILICON POWER TRANSISTOR
2SD2164
NPN SILICON EPITAXIAL TRANSISTOR
FOR LOW-FREQUENCY POWER AMPLIFIERS AND LOW-SPEED SWITCHING
The 2SD2164 is a single power transistor developed especially
for high h
FE
. This transistor is ideal for simplifying drive circuits and
reducing power dissipation because its h
FE
is as high as that of
Darlington transistors, but it is a single transistor.
In addition, this transistor features a small resin insulated
package, thus contributing to high-density mounting and mounting
cost reduction.
PACKAGE DRAWING (UNIT: mm)
FEATURES
• High h
FE
and low V
CE(sat)
:
h
FE
≅
1,300 TYP. (V
CE
= 5.0 V, I
C
= 0.5 A)
V
CE(SAT)
≅
0.3 V TYP. (I
C
= 2.0 A, I
B
= 20 mA)
• Full mold package that does not require an insulating board or
insulation bushing
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
°
Parameter
Collector to base voltage
Collector to emitter voltage
Emitter to base voltage
Collector current (DC)
Collector current (pulse)
Base current (DC)
Total power dissipation
Total power dissipation
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
I
B(DC)
P
T
(T
C
= 25°C)
P
T
(T
A
= 25°C)
T
j
T
stg
Ratings
60
60
7.0
3.0
5.0
Note
0.5
20
2.0
150
−55
to +150
Unit
V
V
V
A
A
A
W
W
°C
°C
(OHFWURGH &RQQHFWLRQ
%DVH
&ROOHFWRU
(PLWWHU
Note
PW
≤
300
µ
s, duty cycle
≤
10%
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No. D15606EJ3V0DS00 (3rd edition)
Date Published April 2002 N CP(K)
Printed in Japan
©
