1N4448HWS
SURFACE MOUNT FAST SWITCHING DIODE
Features
•
•
•
•
•
•
Fast Switching Speed
Small Surface Mount Package
For General Purpose Switching Applications
High Conductance
Lead Free/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Mechanical Data
•
•
•
•
•
•
Case: SOD-323
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Leads: Matte Tin Finish annealed over Alloy 42 leadframe (Lead
Free Plating). Solderable per MIL-STD-202, Method 208
Polarity: Cathode Band
Weight: 0.004 grams (approximate)
SOD-323
Top View
Ordering Information
(Note 3)
Part Number
1N4448HWS-7-F
1N4448HWS-13-F
Notes:
Case
SOD-323
SOD-323
Packaging
3,000/Tape & Reel
10,000/Tape & Reel
1. No purposefully added lead.
2. Diodes Inc.`s “Green” Policy can be found on our website at http://www.diodes.com
3. For packaging details, go to our website at http://www.diodes.com.
Marking Information
T5
Cathode Band
T5 = Product Type Marking Code
1N4448HWS
Document number: DS30196 Rev. 10 - 2
1 of 4
www.diodes.com
November 2010
© Diodes Incorporated
1N4448HWS
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Non-Repetitive Peak Reverse Voltage
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current
Average Rectified Output Current
Non-Repetitive Peak Forward Surge Current
Symbol
V
RM
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
O
@ t = 1.0μs
@ t = 1.0s
I
FSM
Value
100
80
57
500
250
4.0
1.0
Unit
V
V
V
mA
mA
A
Thermal Characteristics
Characteristic
Power Dissipation (Note 4)
Thermal Resistance Junction to Ambient Air (Note 4)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
200
625
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Reverse Breakdown Voltage (Note 5)
Forward Voltage
Symbol
V
BR(R)
V
FM
Min
80
0.62
⎯
⎯
⎯
⎯
⎯
⎯
Max
⎯
0.72
0.855
1.0
1.25
100
50
30
25
3.5
4.0
Unit
V
V
Test Condition
I
R
= 100μA
I
F
= 5.0mA
I
F
= 10mA
I
F
= 100mA
I
F
= 150mA
V
R
= 80V
V
R
= 75V, T
J
= 150°C
V
R
= 25V, T
J
= 150°C
V
R
= 20V
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100Ω
Peak Reverse Current (Note 5)
Total Capacitance
Reverse Recovery Time
Notes:
I
RM
C
T
t
rr
nA
μA
μA
nA
pF
ns
4. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com.
5. Short duration pulse test used to minimize self-heating effect.
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
300
100
P
D
, POWER DISSIPATION (mW)
200
10
T
A
= 25
°
C
Note 4
100
1
0
0
50
25
75
125
150
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Power Derating Curve
175
0.1
0
1,000
400
600
800
200
V
F
, INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig. 2 Typical Forward Characteristics
1N4448HWS
Document number: DS30196 Rev. 10 - 2
2 of 4
www.diodes.com
November 2010
© Diodes Incorporated
1N4448HWS
I
R
, INSTANTANEOUS REVERSE CURRENT (
μ
A)
10.0
4
1.0
C
T
, TOTAL CAPACITANCE (pF)
T
A
= 100
°
C
3
T
A
= 75
°
C
0.10
T
A
= 50
°
C
T
A
= 25
°
C
2
0.01
T
A
= -30
°
C
T
A
= 0
°
C
1
0.001
0
40
60
80
20
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
0
0
1
2
4
5
6
3
V
R
, DC REVERSE VOLTAGE (V)
Fig. 4 Total Capacitance vs. Reverse Voltage
2.5
t
rr
, REVERSE RECOVERY TIME (nS)
2.0
1.5
1.0
0.5
0
2
4
6
8
10
I
F
, FORWARD CURRENT (mA)
Fig. 5 Reverse Recovery Time vs. Forward Current
0
Package Outline Dimensions
C
H
B
A
M
L
K
J
SOD-323
Dim
Min
Max
A
0.25
0.35
B
1.20
1.40
C
2.30
2.70
H
1.60
1.80
J
0.00
0.10
K
1.0
1.1
L
0.20
0.40
M
0.10
0.15
0°
8°
α
All Dimensions in mm
1N4448HWS
Document number: DS30196 Rev. 10 - 2
3 of 4
www.diodes.com
November 2010
© Diodes Incorporated
1N4448HWS
Suggested Pad Layout
C
X
Dimensions Value (in mm)
Z
3.75
G
1.05
X
0.65
Y
1.35
C
2.40
Y
G
Z
