5Vdc or 3.3Vdc • MINIATURE CERAMIC SURFACE MOUNT • HCMOS OR TTL
PROGRAMMABLE CLOCK OSCILLATORS
ASLP and ASVP
FEATURES:
7.0 x 5.0 x 1.6 mm
• Wide range of frequency up to 125MHz using PLL technology. • Reflow soldering.
• Quick delivery within one to five days for small quantities.
• Tristate E/ D or Stand-By function.
• Ultra miniature low profile SMD package.
• Hermetically seam welded.
APPLICATIONS:
• Clocks for a wide range of applications.
STANDARD SPECIFICATIONS
PARAMETERS
STA
Range
S
ICATION
Frequency
NDARD
(F )
PECIF
1.00MHz - 125MHz
S
o
AS LP
AS LPT
ASVP
1.00MHz - 106.25MHz
Operating Temperature (T
OPR
)
-20°C to +70°C
( See Options)
Storage Temperature
(T
STO
)
-55°C to +125°C
Frequency Stability
(∆F/ F
o
)
±50ppm max.
( See Options )
Supply Voltage
(V
dd
)
5.0Vdc ±10%
3.3Vdc ±10%
(I
dd
)
45m A max.
25m A max.
Input Current
Duty Cycle or Symmetry
45/55% max.at 1/2 VDD 45 / 55% max.at 1.4 VDC 45/55% max.at 1/2 VDD
Rise and Fall Times (T
R
/
T
F
)
4ns max.
Output Load
25pF max.
5TTL
15pF max.
Output Voltage
(V
OH
)
0.9 *V
dd
min.
2.4V min.
0.7 *V
dd
min.
(V
OL
)
0.4V max.
0.4V max.
0.2 *Vdd max.
Start-up Time
(T
OSC
)
10ms max.
Tristate (OE) Function
Disable current OE
(I
DIS
)
Stand - By current (option B)(I
STB
)
Jitter
Peak to peak
RMS One sigma
V
IH
: 2.0V min. Oscillation
V
IL
: 0.8V max. Hi Impedance
30mA max.
50µA max.
±250ps max. for F< 40MHz, ±90ps typ.
±100ps max. for F> 40MHz, ±50ps typ.
±50ps max. for F< 40MHz, ±25ps typ.
±30ps max. for F> 40MHz, ±15ps typ.
V
IH
: 0.7*VDDmin.
V
IH
: 0.2*VDDmax.
15mA max.
20µA max.
±250ps max. for
F< 40MHz, ±90ps typ.
±100ps max. for
F> 40MHz, ±50ps typ.
±50ps max. for
F< 40MHz, ±25ps typ.
±40ps max. for
F>40MHz, ±20ps typ.
* Pin 1 has internal pull-up resistor which allow Pin 1 to be left floating ( enable high).
Connect a By-Pass capacitor 0.01
µ
F between Vdd and GND.
Environmental and mechanical specifications see appendix C. Group 2.
Test circuit, waveforms,see appendix B. Reflow profile, see appendix E.
Tape and Reel, see appendix H.(1,000 pcs./reel).
Dimensions: Inches (mm)
ORDERING OPTIONS
ASXPX
L or V
- Frequency
-
Temperature
-
Overall Frequency Stability
-
Stand By
-B
- Packaging
XXX.XXX MHz
-F for -30°C to +70°C
-N for -30°C to +85°C
-L for -40°C to +85°C
-J for + 20pmm max.*
-R for + 25pmm max.*
-K for + 30pmm max.
-H for + 35pmm max.
T for Tape and Reel
Pin
1
2
3
4
Function
OE or PD
GND
Output
Vdd
T or Blank
* Standard temperature only.
Please call us for other tighter spec.
MARKING w/o OPTIONS:
- ALPX
(X.XX
frequency)
- 042104 (Six
digit lot and blank date code,
Ex: ALP80.0, ALP4.00)
ABRACON IS
ISO
9001
/ QS
9000
CERTIFIED
rev2.1-4/06
MARKING w/ OPTIONS:
- AX.XXRB or LB
(X.XX
frequency)
- 042104 (R
for stability. or L temp. & B for stand-by
Six digit lot and blank date code, Ex: A125LB, A66.6B, A27.0R)
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
