BAV199W
DUAL SURFACE MOUNT LOW LEAKAGE DIODE
Features
•
•
•
•
•
Surface Mount Package Ideally Suited for Automated Insertion
Suitable for ultra-low leakage current applications, including
high-precision instrumentation and portable electronics
Lead Free By Design/RoHS Compliant (Note 1)
Halogen and Antimony Free "Green" Device (Notes 2 & 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
•
Case: SOT323
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish
⎯
Matte Tin Finish annealed over Alloy 42
leadframe. Solderable per MIL-STD-202, Method 208
Polarity: See Diagram
Weight: 0.006 grams (approximate)
SOT323
Top View
Top View
Internal Schematic
Ordering Information
(Notes 4 & 5)
Part Number
BAV199W-7
Notes:
Case
SOT323
Packaging
3,000/Tape & Reel
1. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. No purposely added lead.
2. Halogen and Antimony free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
3. Diodes Inc.`s “Green” Policy can be found on our website at http://www.diodes.com
4. For packaging details, go to our website at http://www.diodes.com.
5. Product manufactured with Date Code V9 (week 33, 2008) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
Marking Information
K52
K52= Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: Z = 2012)
M = Month (ex: 9 = September)
Date Code Key
Year
Code
Month
Code
2004
R
Jan
1
Feb
2
2005
S
Mar
3
…..
…..
Apr
4
YM
2012
Z
May
5
2013
A
Jun
6
Jul
7
2014
B
Aug
8
2015
C
Sep
9
Oct
O
2016
D
Nov
N
2017
E
Dec
D
BAV199W
Document number: DS30462 Rev. 7 - 2
1 of 4
www.diodes.com
February 2012
© Diodes Incorporated
BAV199W
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current (Note 6)
Repetitive Peak Forward Current (Note 6)
Non-Repetitive Peak Forward Surge Current
Single diode
Double diode
@ t = 1.0μs
@ t = 1.0ms
@ t = 1.0s
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
FRM
I
FSM
Value
85
60
160
140
500
4.0
1.0
0.5
Unit
V
V
mA
mA
A
Thermal Characteristics
Characteristic
Power Dissipation (Note 6)
Thermal Resistance Junction to Ambient Air (Note 6)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
200
625
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Reverse Breakdown Voltage (Note 7)
Forward Voltage
Symbol
V
(BR)R
V
F
Min
85
⎯
Typ
⎯
⎯
Max
⎯
0.90
1.0
1.1
1.25
5.0
80
⎯
3.0
Unit
V
V
nA
nA
pF
μs
Test Condition
I
R
= 100μA
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
V
R
= 75V
V
R
= 75V, T
J
= 150°C
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100Ω
Leakage Current (Note 7)
Total Capacitance
Reverse Recovery Time
Notes:
I
R
C
T
t
rr
⎯
⎯
⎯
⎯
2
⎯
6. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com.
7. Short duration pulse test used to minimize self-heating effect.
250
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
300
P
D
, POWER DISSIPATION (mW)
1,000
100
200
Note 6
150
10
T
A
= 150°C
T
A
= 125°C
100
1
T
A
= 85°C
T
A
= 25°C
T
A
= -55°C
50
0
0
0.1
0
0.2
0.4
0.6
0.8
1.0
1.2 1.4
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
25
50
75
100
125
150
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 1 Power Derating Curve, Total Package
BAV199W
Document number: DS30462 Rev. 7 - 2
2 of 4
www.diodes.com
February 2012
© Diodes Incorporated
BAV199W
100
2.0
1.8
C
T
, TOTAL CAPACITANCE (pF)
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0.1
0
0
10
20
30
40
50
60
70 80
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
0
10
20
30
40
V
R
, DC REVERSE VOLTAGE (V)
Fig. 4 Total Capacitance vs. Reverse Voltage
f = 1MHz
I
R
, INSTANTANEOUS REVERSE CURRENT (nA)
10
T
A
= 150°C
T
A
= 125°C
T
A
= 85°C
1
T
A
= -55°C
T
A
= 25°C
200
180
I
F
, FORWARD CURRENT (mA)
160
140
120
100
80
60
40
20
0
0
50
100
150
200
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 5 Current Derating Curve, Per Element
Package Outline Dimensions
A
B C
G
H
K
M
J
D
L
SOT323
Dim
Min
Max
Typ
A
0.25
0.40
0.30
B
1.15
1.35
1.30
C
2.00
2.20
2.10
D
-
-
0.65
G
1.20
1.40
1.30
H
1.80
2.20
2.15
J
0.0
0.10
0.05
K
0.90
1.00
1.00
L
0.25
0.40
0.30
M
0.10
0.18
0.11
0°
8°
-
α
All Dimensions in mm
BAV199W
Document number: DS30462 Rev. 7 - 2
3 of 4
www.diodes.com
February 2012
© Diodes Incorporated
BAV199W
Suggested Pad Layout
Y
Z
C
Dimensions Value (in mm)
Z
2.8
X
0.7
Y
0.9
C
1.9
E
1.0
X
E
