BAT760
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER
Features
Very Low Forward Voltage Drop
Guard Ring Construction for Transient Protection
High Conductance
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
An Automotive-Compliant Part is Available Under Separate
Data Sheet (BAT760Q)
Mechanical Data
Case: SOD323
Case Material – Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: Cathode Band
Terminals: Finish – Matte Tin Annealed Over Alloy 42 Leadframe.
Solderable per MIL-STD-202, Method 208
e3
Weight: 0.004 grams (Approximate)
Top View
Ordering Information
(Note 4)
Part Number
BAT760-7
Notes:
Case
SOD323
Packaging
3,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at https://www.diodes.com/design/support/packaging/diodes-packaging/.
Marking Information
LZ & LZ = Product Type Marking Code
BAT760
Document number: DS30498 Rev. 9 - 2
1 of 5
www.diodes.com
December 2017
© Diodes Incorporated
BAT760
Maximum Ratings
(@T
A
= +25°C unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
Non-Repetitive Peak Forward Surge Current
8.3ms Single Half Sine-Wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
Value
30
21
1
5.5
Unit
V
V
A
A
Thermal Characteristics
Characteristic
Power Dissipation (Note 1)
Typical Thermal Resistance Junction to Ambient (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
θJA
T
J,
T
STG
Value
235
426
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
(@T
A
= +25°C unless otherwise specified.)
Characteristic
Reverse Breakdown Voltage (Note 6)
Forward Voltage Drop
Symbol
V
(BR)R
V
F
Min
30
Typ
245
320
495
3.0
3.5
5.0
25
Max
270
350
550
10
20
50
Unit
V
mV
Test Conditions
I
R
= 500µA
I
F
= 10mA
I
F
= 100mA
I
F
= 1A
V
R
= 5V
V
R
= 8V
V
R
= 15V
f = 1MHz, V
R
= 5VDC
Leakage Current (Note 6)
Total Capacitance
Notes:
I
R
C
T
µA
pF
5. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com/package-outlines.html.
6. Short duration pulse test used to minimize self-heating effect.
BAT760
Document number: DS30498 Rev. 9 - 2
2 of 5
www.diodes.com
December 2017
© Diodes Incorporated
BAT760
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
10
1
0.1
0.01
0.001
0.2
0.4
0.6
0.8
1.0
0
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
0
10
20
30
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
60
f = 1MHz
2.0
50
C
T
, TOTAL CAPACITANCE (pF)
I
F(AV)
, AVERAGE FORWARD CURRENT (A)
1.5
40
30
1.0
20
0.5
10
0
0
10
5
15
20
V
R
, DC REVERSE VOLTAGE (V)
Fig. 3 Total Capacitance vs. Reverse Voltage
0
0
25
50
75
100
125
T
T
, TERMINAL TEMPERATURE ( °C)
Fig. 4 Forward Current Derating Curve
150
BAT760
Document number: DS30498 Rev. 9 - 2
3 of 5
www.diodes.com
December 2017
© Diodes Incorporated
BAT760
Package Outline Dimensions
Please see http://www.diodes.com/package-outlines.html for the latest version.
SOD323
A2
A1
a
c
He
E
L
b
D
SOD323
Dim Min Max Typ
A1
--
0.10 0.05
A2
1.00 1.10 1.05
b
0.25 0.35 0.30
c
0.10 0.15 0.11
D
1.20 1.40 1.30
E
1.60 1.80 1.70
He
2.30 2.70 2.50
L
0.20 0.40 0.30
a
0º
8º
--
All Dimensions in mm
Suggested Pad Layout
Please see http://www.diodes.com/package-outlines.html for the latest version.
SOD323
X1
Y
X
Dimensions Value (in mm)
X
0.590
X1
2.700
Y
0.450
BAT760
Document number: DS30498 Rev. 9 - 2
4 of 5
www.diodes.com
December 2017
© Diodes Incorporated
BAT760
