DZT591C
PNP SURFACE MOUNT TRANSISTOR
Features
•
•
•
•
•
•
Epitaxial Planar Die Construction
Complementary NPN Type Available (DZT491)
Ideally Suited for Automated Assembly Processes
Ideal for Medium Power Switching or Amplification Applications
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 3)
3
2
1
NEW PRODUCT
4
Mechanical Data
•
•
•
•
•
•
•
Case: SOT-223
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Finish - Matte Tin annealed over Copper Leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Marking & Type Code Information: See Page 3
Ordering Information: See Page 3
Weight: 0.115 grams (approximate)
@T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
d
T
j
, T
STG
SOT-223
3 E
C 4
2 C
1 B
TOP VIEW
1
COLLECTOR
2,4
BASE
EMITTER
3
Schematic and Pin Configuration
Maximum Ratings
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Continuous Current (Note 3)
Peak Collector Current
Base Current
Power Dissipation (Note 3)
Operating and Storage Temperature Range
Value
-80
-60
-5
-1
-2
-200
1
-55 to +150
Unit
V
V
V
A
A
mA
W
°C
Electrical Characteristics
Characteristic
OFF CHARACTERISTICS (Note 4)
Collector-Base Cutoff Current
Emitter-Base Cutoff Current
Collector-Emitter Cutoff Current
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
ON CHARACTERISTICS (Note 4)
Collector-Emitter Saturation Voltage
@T
A
= 25°C unless otherwise specified
Symbol
I
CBO
I
EBO
I
CES
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
V
CE(SAT)
Min
⎯
⎯
⎯
-80
-60
-5
⎯
⎯
100
100
80
15
⎯
⎯
150
⎯
Typ
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
13
Max
-100
-100
-100
⎯
⎯
⎯
-0.3
-0.6
⎯
300
⎯
⎯
-1.2
-1
⎯
⎯
Unit
nA
nA
nA
V
V
V
V
V
⎯
⎯
⎯
⎯
V
V
V
CB
= -60V
V
EB
= -4V
V
CES
= -60V
I
C
= 100μA
I
C
= 10mA
I
E
= 100μA
I
C
= -500mA, I
B
= -50mA
I
C
= -1A, I
B
= -100mA
V
CE
= -5V, I
C
= -1mA
V
CE
= -5V, I
C
= -500mA
V
CE
= -5V, I
C
= -1A
V
CE
= -5V, I
C
= -2A
I
C
= -1A, I
B
= -100mA
I
C
= -1A, V
CE
= -5V
Test Conditions
DC Current Gain
Base-Emitter Saturation Voltage
Base-Emitter Turn-On Voltage
SMALL SIGNAL CHARACTERISTICS
Current Gain-Bandwidth Product
Output Capacitance
Notes:
1.
2.
3.
4.
h
FE
V
BE(SAT)
V
BE(on)
f
T
C
obo
MHz V
CE
= -10V, I
C
= -50mA, f = 100MHz
pF V
CB
= -10V, f =1MHz
No purposefully added lead.
Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
Device mounted on FR-4 PCB, pad layout as shown on page 4 or in Diodes Inc. suggested pad layout document AP02001, which can be found on our
website at http://www.diodes.com/datasheets/ap02001.pdf.
Measured under pulsed conditions. Pulse width = 300ms. Duty cycle
≤
2%.
DS31127 Rev. 2 - 2
1 of 4
www.diodes.com
DZT591C
© Diodes Incorporated
Suggested Pad Layout: (Based on IPC-SM-782)
