DATA SHEET
SILICON POWER TRANSISTOR
2SA1413-Z
PNP SILICON TRIPLE DIFFUSED TRANSISTOR
DESCRIPTION
The 2SA1413-Z is designed for High Voltage Switching, especially in
Hybrid Integrated Circuits.
<R>
PACKAGE DRAWING (Unit: mm)
6.5 ±0.2
5.0 ±0.2
4.4 ±0.2
Note
5.6 ±0.3
9.5 ±0.5
1.5
−0.1
+0.2
FEATURES
• High Speed: t
f
≤
1.0
μ
s
• Complement to 2SC3632-Z
5.5 ±0.2
• High Voltage: V
CEO
=
−600
V
1 2 3
0.5 ±0.1
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Collector to base voltage
Collector to emitter voltage
Base to emitter voltage
Collector current (DC)
Collector current (pulse)
Note 1
Note 2
2.3 ±0.3
V
V
V
A
A
W
°C
°C
TO-252 (MP-3Z)
2.3 ±0.3
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
P
T
T
j
T
stg
−600
−600
−7
−1.0
−2.0
2.0
150
−55
to +150
0.15 ±0.15
1.
2.
3.
4.
Base
Collector
Emitter
Collector Fin
Total power dissipation (T
A
= 25°C)
Junction temperature
Storage temperature
Note
The depth of notch at the top of the fin is
from 0 to 0.2 mm.
Notes 1.
PW
≤
10 ms, Duty Cycle
≤
50%
2.
When mounted on ceramic substrate of 7.5 cm
2
× 0.7 mm
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. D18251EJ4V0DS00 (4th edition)
(Previous No. TC-1636A)
Date Published June 2006 NS CP(K)
Printed in Japan
1.0 ±0.5
0.4 MIN.
0.5 TYP.
2.5 ±0.5
4
2.3 ±0.2
0.5 ±0.1
Note
0.5 ±0.1
1985, 2006
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
