DSS5320T

20V LOW V

CE(sat)

PNP SURFACE MOUNT TRANSISTOR

Features

•

Epitaxial Planar Die Construction

Ideal for Medium Power Amplification and Switching

“Lead Free”, RoHS Compliant (Note 1)

Halogen and Antimony Free. "Green" Device (Note 2)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

•

Case: SOT-23

Case Material: Molded Plastic, "Green” Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Finish — Matte Tin annealed over Copper leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.008 grams (approximate)

SOT-23

Top View

Device Symbol

Pin-Out Top

Ordering Information

(Note 3)

Product

DSS5320T-7

Notes:

Marking

ZP4

Reel size (inches)

Tape width (mm)

8mm

Quantity per reel

3,000

1. No purposefully added lead.

2. Diodes Inc’s “Green” Policy can be found on our website at http://www.diodes.com

3. For packaging details, go to our website at http://www.diodes.com

Marking Information

ZP4

ZP4 = Product Type Marking Code

YM = Date Code Marking

Y = Year (ex: V = 2008)

M = Month (ex: 9 = September)

Date Code Key

Year

Code

Month

Code

2009

Jan

Feb

2010

Mar

2011

Apr

May

2012

Jun

2013

Jul

Aug

2014

Sep

2015

Oct

Nov

2016

Dec

DSS5320T

Document number: DS31620 Rev. 2 - 2

1 of 5

www.diodes.com

October 2010

DSS5320T

Suggested Pad Layout

Dimensions Value (in mm)

2.9

0.8

0.9

2.0

1.35
