DATA SHEET
MOS FIELD EFFECT TRANSISTOR
2SK3111
SWITCHING
N-CHANNEL POWER MOS FET
INDUSTRIAL USE
DESCRIPTION
The 2SK3111 is N channel MOS FET device that
features a low on-state resistance and excellent
switching characteristics, and designed for high voltage
applications such as DC/DC converter, actuator driver.
ORDERING INFORMATION
PART NUMBER
2SK3111
2SK3111-S
2SK3111-ZJ
PACKAGE
TO-220AB
TO-262
TO-263
FEATURES
•
Gate voltage rating ±30 V
•
Low on-state resistance
R
DS(on)
= 180 mΩ MAX. (V
GS
= 10 V, I
D
= 10 A)
•
Low input capacitance
C
iss
= 1000 pF TYP. (V
DS
= 10 V, V
GS
= 0 V)
•
Avalanche capability rated
•
Built-in gate protection diode
•
Surface mount device available
ABSOLUTE MAXIMUM RATINGS (T
A
= 25 °C)
Drain to source voltage (V
GS
= 0 V)
Gate to source voltage (V
DS
= 0 V)
Drain current (DC) (T
C
= 25 °C)
Drain current (pulse)
Note1
V
DSS
V
GSS
I
D(DC)
I
D(pulse)
P
T1
P
T2
T
ch
T
stg
200
±30
±20
±60
1.5
65
150
−55
to +150
20
100
V
V
A
A
W
W
°C
°C
A
mJ
Total power dissipation (T
A
= 25 °C)
Total power dissipation (T
C
= 25 °C)
Channel temperature
Storage temperature
Single avalanche current
Single avalanche energy
Note2
Note2
I
AS
E
AS
Notes 1.
PW
≤
10
µ
s, Duty Cycle
≤
1 %
2.
Starting T
ch
= 25 °C, V
DD
= 100 V, R
G
= 25
Ω,
V
GS
= 20 V→0 V
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No.
D13334EJ2V0DS00 (2nd edition)
Date Published May 2001 NS CP(K)
Printed in Japan
