THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
3000 ± 30
REV.
REVISION
DESCRIPTION
DATE
APPROVED
P1
1
5
6
10
P2
A
A
3 4 5
10
6
5
1
1
5.5 ±
0.3
0.1
2 4 5
5.5 ±
0.3
0.1
10
8
6
5
3
1
9
7
4
2
WIRING:
P1
110 ± 10
6
1
2
3
5
6
7
8
9
10
SHIELD
COLOR
RED
WHITE
GREEN
BLACK
BLUE
YELLOW
DRAIN WIRE
PURPLE
ORANGE
BRAID
P2
1
2
3
5
6
7
8
9
10
SHIELD
A-A
8”
CONTROLLED
No.
1
2
3
4
5
6
CABLE
PARTS NAME
SPECIFICATION STANDARD
UL 20276 O.D. 5.5mm COLOR: BLACK
QTY REMARKS
1
1
1
14
3
2
g
g
MICRO USB3.0 A B M 10PIN GOLD PLATED 15U” SHELL NICKEL PLATED INSULATOR BLACK
MICRO USB3.0 B M 10PIN GOLD PLATED
15U” SHELL NICKEL PLATED INSULATOR BLACK
6”
NOTES:
1. CABLE: UL20276
(1Px30AWG+D+AL+MY)x2C+1Px30AWG+2Cx24AWG+AL+B
OUTER JACKET: BLACK, O.D.: 5.5mm
2. CONNECTORS: MICRO USB 3.0 A MALE TO MICRO USB 3.0 B MALE
3. HOOD: MOLDED TYPE, COLOR: BLACK
4. PACKING: 1PC/POLYBAG
5. RoHS COMPLIANT
B
PVC
PE
CABLE TIE
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
45P PVC BLACK
CLEAR PE
L=9cm COLOR: BLACK
Qualtek Electronics Corp.
Part Number:
Description:
WCI DIVISION
3023031-03M
MICRO USB 3.0 A/M - MICRO USB 3.0 B/M
UNIT: mm
Drawn / Date
R.Nuti
06-25-10
Checked / Date
06-25-10
Approved / Date
LY / 06-25-10
