BLM10A100SPT

Description
Ferrite Chip, 1 Function(s), 0.5A, EIA STD PACKAGE SIZE 0402, 2 PIN
CategoryAnalog mixed-signal IC    filter
File Size180KB,4 Pages
ManufacturerMurata
Websitehttps://www.murata.com
Download Datasheet Parametric View All

BLM10A100SPT Overview

Ferrite Chip, 1 Function(s), 0.5A, EIA STD PACKAGE SIZE 0402, 2 PIN

BLM10A100SPT Parametric

Parameter NameAttribute value
MakerMurata
package instructionEIA STD PACKAGE SIZE 0402, 2 PIN
Reach Compliance Codeunknown
ECCN codeEAR99
shell code0402
structureChip Bead
Maximum DC resistance0.05 Ω
filter typeFERRITE CHIP
maximum frequency100 MHz
minimum frequency100 MHz
high0.5 mm
length1 mm
Manufacturer's serial numberBLM10A
MaterialFerrite
Installation typeSURFACE MOUNT
Number of functions1
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Output impedance10 OHM Ω
method of packingTAPE AND REEL
physical sizeL1XB0.5XH0.5 (mm)
Rated current0.5 A
seriesBLM 10A
width0.5 mm
SURFACE MOUNT EMI FILTERS
CHIP FERRITE BEADS
BLM
A Series
The BLM
A Series ferrite beads provide outstanding
electrical characteristics in packages as small as 0402.
For noise applications covering a wide frequency range.
FEATURES
I
Suitable for flow and reflow soldering
I
Wide temperature range
I
High Z characteristics
APPLICATIONS
I
I/O ports, DC power lines, and Signal lines
PART NUMBERING SYSTEM
BLM
11
A
471
SG
PT
CHIP FERRITE
SERIES
SIZE
10: 1.0 x 0.5mm
11: 1.6 x 0.8mm
21: 2.0 x 1.25mm
31: 3.2 x 1.6mm
41: 4.5 x 1.6mm
STANDARD
SIGNAL
A: Standard
IMPEDANCE CODE
at 100MHz
471: 470 ohms
121: 120 ohms
102: 1000 ohms
CHARACTERISTICS
PACKAGING CODE
PB: Bulk
PT: Tape 7” Reel
PT1: Tape 13” Reel
SPECIFICATIONS
Dimensions: mm
Part Number
Impedance
(Ohms)
Typ. @ 100MHz
10
70
200
0.5 ± 0.1
Rated
Current
(mA)
500
DCR
(Ohms max.)
0.05
0.40
0.50
Operating
Temperature
Range
0402
‚
BLM10A100S
‚
BLM10A700S
0.25 ± 0.1
‚
BLM10A121S
‚
BLM10A221SG
‚
BLM10A601SG
‚
BLM10A102SG
‚
BLM11A121S
‚
BLM11A151SG
‚
BLM11A221S
120
220
600
50
1000
120
150
220
200
330
470
100
1.0 ± 0.1
0.5 ± 0.1
0.70
1.10
1.50
0.2
0.25
0.3
0.45
–55 ~ +125°C
0603
0.4 ± 0.2
0.8 ± 0.15
‚
BLM11A331SG
‚
BLM11A471SG
‚
BLM11A601S
‚
BLM11A102S
1.6 ± 0.15
0.8 ± 0.15
0.5
600
1000
100
0.7
‚
Available as standard through authorized Murata Electronics Distributors.
