2SC4783-L4-A

Description
100mA, 50V, NPN, Si, SMALL SIGNAL TRANSISTOR
CategoryDiscrete semiconductor    The transistor
File Size38KB,4 Pages
ManufacturerRenesas Electronics Corporation
Websitehttps://www.renesas.com/
Download Datasheet Parametric Compare View All

2SC4783-L4-A Overview

100mA, 50V, NPN, Si, SMALL SIGNAL TRANSISTOR

2SC4783-L4-A Parametric

Parameter NameAttribute value
package instructionSMALL OUTLINE, R-PDSO-G3
Reach Compliance Codecompli
ECCN codeEAR99
Maximum collector current (IC)0.1 A
Collector-emitter maximum voltage50 V
ConfigurationSINGLE
Minimum DC current gain (hFE)90
JESD-30 codeR-PDSO-G3
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeNPN
Certification statusNot Qualified
surface mountYES
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Transistor component materialsSILICON
Nominal transition frequency (fT)250 MHz
Base Number Matches1
DATA SHEET
NPN SILICON EPITAXIAL TRANSISTOR
2SC4783
NPN SILICON EPITAXIAL TRANSISTOR
DESCRIPTION
The 2SC4783 is NPN silicon epitaxial transistor.
PACKAGE DRAWING (Unit: mm)
0.3 ± 0.05
0.1
+0.1
–0.05
FEATURES
1.6 ± 0.1
0.8 ± 0.1
High DC current gain: h
FE2
= 200 TYP.
High voltage: V
CEO
= 50 V
3
0 to 0.1
2
0.2
+0.1
–0
0.5
0.5
0.6
0.75 ± 0.05
1
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current (DC)
Collector Current (pulse)
Note1
Note2
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
P
T
T
j
T
stg
60
50
5.0
100
200
200
150
–55 to + 150
V
V
V
mA
mA
mW
°C
°C
1.0
1.6 ± 0.1
Total Power Dissipation (T
A
= 25°C)
Junction Temperature
Storage Temperature Range
1: Emitter
2: Base
3: Collector
Notes 1.
PW
10 ms, Duty Cycle
50%
2
2.
When mounted on ceramic substrate of 3.0 cm x 0.64 mm
ELECTRICAL CHARACTERISTICS (T
A
= 25°C)
CHARACTERISTICS
Collector Cut-off Current
Emitter Cut-off Current
DC Current Gain
Note
SYMBOL
I
CBO
I
EBO
h
FE1
h
FE2
TEST CONDITIONS
V
CB
= 60 V, I
E
= 0
V
EB
= 5.0 V, I
C
= 0
V
CE
= 6.0 V, I
C
= 0.1 mA
V
CE
= 6.0 V, I
C
= 1.0 mA
V
CE
= 6.0 V, I
C
= 1.0 mA
I
C
= 100 mA, I
B
= 10 mA
I
C
= 100 mA, I
B
= 10 mA
V
CE
= 6.0 V, I
E
=
−10
mA
V
CE
= 6.0 V, I
E
= 0, f = 1.0 MHz
MIN.
TYP.
MAX.
100
100
UNIT
nA
nA
50
90
200
0.62
0.15
0.86
150
250
3.0
4.0
0.3
1.0
600
V
V
V
MHz
pF
Base to Emitter Voltage
Note
Note
V
BE
V
CE(sat)
V
BE(sat)
f
T
C
ob
Collector Saturation Voltage
Base Saturation Voltage
Gain Bandwidth Product
Output Capacitance
Note
Note
Pulsed: PW
350
µ
s, Duty Cycle
2%
h
FE
CLASSFICATION
Marking
h
FE2
L4
90 to 180
L5
135 to 270
L6
200 to 400
L7
300 to 600
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all devices/types available in every country. Please check with local NEC representative for
availability and additional information.
Document No.
D15616EJ1V0DS00 (1st edition)
Date Published July 2001 NS CP(K)
Printed in Japan
©
2001
