1. PHYSICAL DIMENSIONS
2.65
R0.04MAX.
1.063 ± 0.003
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
A. @ 115 VAC..........................................6 A RMS MAX
B. @ 250 VAC.........................................6 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.25 mA MAX
B. @ 250 VAC 50Hz.............................0.45 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
/
/
.05
/
/
.10
15
6
.15
16
6
.50
25
30
1.0
30
48
5.0
42
40
10
45
40
30
40
40
1-3.
1-4.
1.15
FUSE HOLDER
2.6 ± 0.003
PANEL CUTOUT
1-5.
0.57
1-6.
FREQ. MHz
2.38
COM. MODE dB
2.17
DIF. MODE dB
1-7.
OPERATING TEMPERATURE.................-25° TO +100° C
SAFETY:
RoHS COMPLIANT
0.43
1-8.
2.57TYP
2. ELECTRICAL SCHEMATIC
0.25
1.06MAX.
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
1-9.
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
L:
C1:
C2:
R:
NOTES:
1. MOUNTING PANEL THICKESS 0.04 TO 0.07 INCHES,
1.3mH
0.1uF
3300pF
2.2MΩ
PPC DIVISION
862-06/002
EMI FILTER
UNIT: in
REV. C
Approved / Date
JJH / 01-15-03
Drawn / Date
B.ZHANG
01-15-03
Checked / Date
01-15-03
