C U I Stack, Inc.,
1999
40
2
Ø45
3-M3x6
3 4
15
Ø30
30¸
º
12
SPECIFICATIONS
OUTPUT WAVEFORM
TYPE
Supply Voltage
Current
Output
Voltage
Sink Current
Signal Risetime
Freq. Response
TTL
C
" ", C
5~12VDC
5~12VDC
24VDC ±10%
P
Signal A
ab cd
Signal B
h
40mA max.
H
L
Vcc - 1V
≤
0.5V
20mA max.
≤
2µS
100kHz max.
STANDARD RESOLUTIONS
ORDERING INSTRUCTIONS
MES40-XXXX
MES40-_ _ _ _-_ _ - _ _ _
100 100 P/R
1000 1000 P/R
Resolution
Shaft diameter:
200 200 P/R
2000 2000 P/R
6 = 6mm
Output Format:
360 360 P/R
3600 3600 P/R
635 = 0.25"
blank= TTL voltage
8 = 8mm
500 500 P/R
5000 5000 P/R
C = Open Coll
(smaller bore sizes
available)
10000 10000P/R
OUTPUT CIRCUITS
TYPE ' '(Voltage)
Vcc
2kΩ
Ø56
Ø8
52
Signal Z
h min
TYPE C (Open Coll)
Vcc
Signal
30mA
max
Input Voltage:
3 = 5~12VDC
±10%
4 = 24VDC
±10%
(type "C" only)
1
h max
PPR
h = P ± 0.75P
P P
a,b,c,d = ±
4 8
Wave Duty Ratio: 50% ± 25%
P=
Signal
20mA
max
0V
CABLE SHIELD
CABLE SHIELD
0V
MECHANICAL
1. Max Shaft Load; radial: 2.0 kgf
axial: 1.0 kgf
2. Moment of Inertia: 4 g•cm
2
3. Angular Acceleration: 1x10
4
rad/S
2
4. Max Slewing Speed: 6000 RPM
5. Starting Torque: 30 gf•cm max.
6. Rotational Life: 1 x 10
7
rpm•hrs
ENVIRONMENTAL
1.
2.
3.
4.
5.
Operating Temp: 0° to +60° C
Storage Temp: -20° to +80° C
Humidity: 90% RH, no condensation
Vibration: 10~ 55 Hz, 1.5 mm, 2 hrs
Shock: 50G, 11ms, 3 axes, 3 reps
C U I Stack, Inc.
9615 SW Allen Blvd. #103
Beaverton, OR 97005
Tel: 503/643-4899 FAX: 503/643-6129
DRAWN BY
UPDATED
CHECKED
RELEASED
JAS
PART NO.
03/07/00
03/07/00
REV.
MES40-XXXX-XX-XXX
A
