Fast
Turn-off Thyristor
Stud
Types P0306SX04# to P0306SX08#
The data sheet on the subsequent pages of this document is a scanned copy of existing
data for this product.
(Rating Report 84TR1 Issue 3)
This data reflects the old part number for this product which is: P214PH02-08.
This part number must
NOT
be used for ordering purposes – please use the ordering
particulars detailed below.
The limitations of this data are as follows:
Device no longer available at grade 02 (200V V
RRM
/V
DRM
)
Only SC outline drawing (W18) in datasheet
The following links will direct you to the appropriate outline drawings
Outline W18
– ¾” Ceramic stud
Outline W25
– ¾” Ceramic stud removed
Where any information on the product matrix page differs from that in the following data,
the product matrix must be considered correct
An electronic data sheet for this product is presently in preparation.
For further information on this product, please contact your local ASM or distributor.
Alternatively, please contact Westcode as detailed below.
Ordering Particulars
P0306
Fixed Type
Code
SX
SC - ¾” Ceramic stud
SD – ¾” Ceramic stud removed
Voltage code
V
RRM
/100
04-08
#
Fixed Turn-off time Code
A = 10µs, B = 12µs, C = 15µs
Typical Order Code: M0139SM120, Forward polarity, 3/8” Ceramic stud, 1200V V
RRM
