2SC5175
TOSHIBA Transistor Silicon NPN Epitaxial Type
2SC5175
High-Current Switching Applications
Unit: mm
•
•
Low collector-emitter saturation voltage: V
CE (sat)
= 0.4 V (max)
(I
C
= 2.5 A, I
B
= 125 mA)
High-speed switching: t
stg
= 0.8 µs (typ.)
Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
DC
Pulse
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
T
j
T
stg
Rating
60
50
5
5
8
1
1.8
150
−55
to 150
Unit
V
V
V
A
A
W
°C
°C
JEDEC
JEITA
TOSHIBA
―
―
2-10T1A
Electrical Characteristics
(Ta = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
DC current gain
Collector-emitter saturation voltage
Base-emitter saturation voltage
Transition frequency
Collector output capacitance
Turn-on time
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
h
FE (2)
V
CE (sat)
V
BE (sat)
f
T
C
ob
t
on
20 µs
I
B1
Switching time
Storage time
t
stg
Input
I
B2
Test Condition
V
CB
= 50 V, I
E
= 0
V
EB
= 6 V, I
C
= 0
I
C
= 10 mA, I
B
= 0
V
CE
= 1 V, I
C
= 1 A
V
CE
= 1 V, I
C
= 2.5 A
I
C
= 2.5 A, I
B
= 125 mA
I
C
= 2.5 A, I
B
= 125 mA
V
CE
= 4 V, I
C
= 1 A
V
CB
= 10 V, I
E
= 0, f = 1 MHz
Weight: 1.5 g (typ.)
Min
―
―
50
100
60
―
―
―
―
―
Typ.
―
―
―
―
―
0.25
1.0
100
45
0.1
Max
1
1
―
320
―
0.4
1.3
―
―
―
Unit
µA
µA
V
V
V
MHz
pF
I
B1
I
B2
Output
12
Ω
―
0.8
―
µs
V
CC
= 30 V
Fall time
t
f
I
B1
=
−I
B2
= 125 mA, duty cycle
≤
1%
―
0.1
―
1
2004-07-26
