3SMC12A: DescriptionSURFACE MOUNT UNI-DIRECTIONAL GLASS PASSIVATED JUNCTION SILICON TRANSIENT VOLTAGE SUPPRESSOR 3000 WATTS; CategoryDiscrete semiconductor diode; File Size656KB，4 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

3SMC12A Overview

SURFACE MOUNT UNI-DIRECTIONAL GLASS PASSIVATED JUNCTION SILICON TRANSIENT VOLTAGE SUPPRESSOR 3000 WATTS

3SMC12A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	_compli
ECCN code	EAR99
Other features	UL RECOGNIZED
Maximum breakdown voltage	15.3 V
Minimum breakdown voltage	13.3 V
Maximum clamping voltage	19.9 V
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-C2
JESD-609 code	e0
Maximum non-repetitive peak reverse power dissipation	3000 W
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	12 V
surface mount	YES
technology	AVALANCHE
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	C BEND
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

3SMC5.0A

THRU

3SMC170A

SURFACE MOUNT

UNI-DIRECTIONAL

GLASS PASSIVATED JUNCTION

SILICON TRANSIENT

VOLTAGE SUPPRESSOR

3000 WATTS, 5.0 THRU 170 VOLTS

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR 3SMC5.0A Series

types are Surface Mount Uni-Directional Glass Passivated

Junction Transient Voltage Suppressors designed to

protect voltage sensitive components from high voltage

transients.

THIS DEVICE IS MANUFACTURED WITH A GLASS

PASSIVATED CHIP FOR OPTIMUM RELIABILITY.

Note: For Bi-directional devices, please refer to the

3SMC5.0CA Series data sheet.

SMC CASE

• This series is UL listed, UL file number E130224

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

MAXIMUM RATINGS:

(TA=25°C unless otherwise noted)

Peak Power Dissipation (Note 1)

Peak Forward Surge Current (JEDEC Method)

Operating and Storage Junction Temperature

SYMBOL

PDM

IFSM

TJ, Tstg

3000

200

-65 to +150

UNITS

°C

ELECTRICAL CHARACTERISTICS:

(TA=25°C unless otherwise noted)

REVERSE

STAND-OFF

VOLTAGE

VRWM

(V)

3SMC5.0A

3SMC6.0A

3SMC6.5A

3SMC7.0A

3SMC7.5A

3SMC8.0A

3SMC8.5A

3SMC9.0A

3SMC10A

3SMC11A

3SMC12A

3SMC13A

3SMC14A

3SMC15A

3SMC16A

3SMC17A

3SMC18A

3SMC20A

3SMC22A

3SMC24A

3SMC26A

3SMC28A

3SMC30A

5.0

6.0

6.5

7.0

7.5

8.0

8.5

9.0

BREAKDOWN

VOLTAGE

VBR @

MIN

(V)

6.40

6.67

7.22

7.78

8.33

8.89

9.44

10.0

11.1

12.2

13.3

14.4

15.6

16.7

17.8

18.9

20.0

22.2

24.4

26.7

28.9

31.1

33.3

MAX

(V)

7.25

7.67

8.30

8.95

9.58

10.23

10.82

11.5

12.8

14.0

15.3

16.5

17.9

19.2

20.5

21.7

23.3

25.5

28.0

30.7

33.2

35.8

38.3

(mA)

1.0

TEST

CURRENT

MAXIMUM

REVERSE

LEAKAGE

CURRENT

@ VRWM

(µA)

1000

500

200

100

5.0

MAXIMUM

CLAMPING

VOLTAGE

@ IPP

(V)

9.2

10.3

11.2

12.0

12.9

13.6

14.4

15.4

17.0

18.2

19.9

21.5

23.2

24.4

26.0

27.6

29.2

32.4

35.5

38.9

42.1

45.4

48.4

PEAK

PULSE

CURRENT

(Note 1)

IPP

(A)

326.0

291.3

267.9

250.0

232.6

220.6

208.4

194.8

176.4

184.8

150.6

139.4

129.4

123.0

115.4

106.6

102.8

92.6

84.4

77.2

71.2

66.0

62.0

CHDE

CHDG

CHDK

CHDM

CHDP

CHDR

CHDT

CHDV

CHDX

CHDZ

CHEE

CHEG

CHEK

CHEM

CHEP

CHER

CHET

CHEV

CHEX

CHEZ

CHFE

CHFG

CHFK

TYPE

MARKING

CODE

Notes: (1) Non-repetitive 10x1,000µs pulse

R8 (20-November 2009)
