05265
DSOT03C
thru
DSOT05C
LOW CAPACITANCE TVS ARRAY
APPLICATIONS
✔
✔
✔
✔
✔
✔
RS-232, RS-422 & RS-423
Cellular Phones
Notebooks
Control & Monitoring Systems
Portable Electroincs
Wireless Bus Protection
IEC COMPATIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 24A, 8/20μs - Level 2(Line-Ground) & Level 3(Line-Line)
DFN-3
DFN-6
FEATURES
✔
ESD Protection > 40 kilovolts
✔
100 Watts Peak Pulse Power per Line (tp = 8/20μs)
✔
Low Clamping Voltage
✔
Available in 3V & 5V
✔
Bidirectional Configuration
✔
RoHS Compliant
MECHANICAL CHARACTERISTICS
✔
DFN-3 Package
✔
Available in Lead-Free Nickel-Paladium-Gold Plating
✔
Solder Reflow Temperature:
Nickel-Paladium-Gold (Ni/Pd/Au) - Sn/Ag/Cu, 96/3.5/0.5: 260-270°C
✔
Flammability Rating UL 94V-0
✔
Device Marking: Marking Code
✔
8mm Tape and Reel Per EIA Standard 481
PIN CONFIGURATION
1
2
3
05265.R1 1/10
1
www.protekdevices.com
DSOT03C
thru
DSOT05C
DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Operating Temperature
Storage Temperature
Peak Pulse Power (tp = 8/20μs) - See Figure 1
Typical Forward Voltage @10mA, 300μs - Square Wave (Note 1)
SYMBOL
T
A
T
STG
PP
P
V
F
VALUE
-55 to 150
-55 to 150
100
1.2
UNITS
°C
°C
W
V
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
(See Note 1)
DEVICE
MARKING
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
@ 1mA
V
(BR)
VOLTS
4.0
6.0
@ 25°C Unless Otherwise Specified
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
P
= 1A
V
C
VOLTS
7.0
9.8
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@8/20μs
V
C
@ I
PP
10.9V @ 10A
12.5V @ 2A
MAXIMUM
LEAKAGE
CURRENT
@V
WM
I
D
μA
30
2
TYPICAL
CAPACITANCE
V
WM
VOLTS
DSOT03C
DSOT05C
3U
5U
3.3
5.0
@0V, 1 MHz
C
pF
9
9
05265.R1 1/10
2
www.protekdevices.com
DSOT03C
thru
DSOT05C
DFN-3 PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE & MOUNTING PAD
DIM
D
PACKAGE DIMENSIONS
MILLIMETERS
MIN
1.14
0.025
0.457
1.14
0.610
0.610
0.30x0.178
MAX
1.24
0.076
0.559
1.24
0.711
0.711
MIN
0.045
0.001
0.018
0.045
0.024
0.024
INCHES
MAX
0.049
0.003
0.022
0.049
0.028
0.028
A
B
C
A
D
G1
L1
L2
B
L3
C
G2
0.406x0.279 0.012x0.007 0.016x0.011
L4
G1
0.787x0.432 0.889x0533 0.031x0.017 0.035x0.021
0.965
0.610
1.067
0.711
0.038
0.024
0.042
0.028
1
L1
2
L3
3
L4
G2
NOTES
1. Dimensioning and tolerances per ANSI Y14.5M, 1985.
2. Controlling dimension in inches.
3. Pin 3 is the cathode (Unidirectional Only)
4. Dimensions are exclusive of mold flash and metal burrs.
TAPE & REEL ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in accordance with EIA 481.
2. Suffix-T7 = 7 Inch Reel - 3,000 pieces per 8mm tape, i.e.,
DSOT05C-T7.
3. Suffix-T13 = 13 Inch Reel - 10,000 pieces per 8mm tape, i.e.,
DSOT05C-T13.
4. Suffix - LF = Lead-Free,
i.e., DSOT05C-LF-T7.
Outline & Dimensions: Rev 0 - 5/07, 06073
L2
Tape & Reel Specifications (Dimensions in millimeters)
Reel Dia.
178mm (7”)/330mm(13”)
Tape Width
8mm
A0
B0
K0
D
E
F
W
P0
P2
P
tmax
0.25
1.38± 0.10 1.38± 0.10 0.62 ± 0.10 1.50 ± 0.10 1.75 ± 0.10 3.50 ± 0.05 8.00 ±0.30 4.00 ±0.10 2.00 ±0.05 4.00 ±0.10
P0
t
D
P2
10 Pitches Cumulative
Tolerance on Tape. ± 0.2
E
Top cover tape
A0
K0
B0
Pin 1
Indicated
by Dot
F
W
P
User Direction of Feed
COPYRIGHT © ProTek Devices 2007
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and
specifications is the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or
specifications of such products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail: sales@protekdevices.com
Web Site: www.protekdevices.com
05265.R1 1/10
4
www.protekdevices.com
